Yamaha YFA1RC (BREEZE) 5VJ2 2003 FRONT FENDER Diagram

FRONT FENDER COMP. (DEEP PURPLISH BLUE SOLID E)

3FA-W2151-60-00

Unavailable

FRONT FENDER COMP. (PASTEL DEEP GREEN)

3FA-W2151-70-00

Unavailable

BOLT, WITH WASHER

90119-06152-00

$2.56

BOLT, WITH WASHER (10V)

90119-06063-00

$5.86

PANEL, FRONT

3FA-23391-80-00

Unavailable

CAP, CLEANER CASE 2

3FA-14422-10-00

$29.73

ELEMENT, AIR CLEANER 2

3FA-14461-00-00

$12.22

SCREW, PAN HEAD

98517-05020-00

$1.26

WASHER(1RW)

92907-05600-00

$0.77

COVER, TOP

3FA-2171A-80-00

Unavailable

NUT(1UX)

90179-05525-00

$6.74

SCREW, BINDING (8R1)

90154-05011-00

$3.49
