Yamaha YFA1D 1992 FRONT FENDER Diagram

#

Description
Price

1

FENDER, FRONT

3FA-W215D-11-00

Unavailable

2

BOLT, WITH WASHER

90119-06152-00

$2.74

3

BOLT, WITH WASHER (10V)

90119-06063-00

$6.29

4

PANEL, FRONT

3FA-23391-30-00

Unavailable

5

CAP, CLEANER CASE 2

3FA-14422-10-00

$30.18

6

ELEMENT, AIR CLEANER 2

3FA-14461-00-00

$12.53

7

SCREW, PAN HEAD

98517-05020-00

$1.35

8

WASHER, PLAIN (646)

92990-05600-00

$0.54

9

COVER, TOP

3FA-W217A-30-00

Unavailable

10

NUT(1UX)

90179-05525-00

$7.21

11

SCREW, BINDING (8R1)

90154-05011-00

$3.74
