Description

Price

1

CAMSHAFT ASSY 1

1D7-12170-03-00

$417.65

2

CAMSHAFT ASSY 2

1D7-12180-03-00

$497.62

3

GEAR, BREAKER DRIVE

1D7-11534-00-00

$55.17

4

DRIVEN GEAR COMP.

1D7-Y115B-00-00

$260.02

5

DRIVE GEAR SET

1D7-W115A-00-00

$158.63

6

GEAR 2

4WM-11544-01-00

$48.63

7

WASHER 1

1D7-11557-00-00

$4.51

8

SPRING

4WM-12216-01-00

$10.63

9

WASHER, PLATE

90201-283U6-00

$4.11

10

CIRCLIP

99009-28400-00

$5.75

11

KEY, STRAIGHT

90282-03002-00

$5.97

12

KEY, STRAIGHT

90282-04001-00

$4.85

13

BOLT, FLANGE

90105-10159-00

$6.95

14

BOLT, WASHER BASED(1TX)

90105-10445-00

$9.68

15

O-RING

93210-53638-00

$14.58

16

O-RING(4MX)

93210-472A9-00

$13.85

17

GUIDE, PUSH ROD

1D7-12155-10-00

$302.71

18

CAP, TENSIONER CASE

5PX-12215-00-00

$6.46

19

HOUSING

1D7-12147-00-00

$151.60

20

HOUSING

1D7-12148-00-00

$230.08

21

O-RING (341)

93210-54175-00

$11.80

22

O-RING (4X7)

93210-54452-00

$9.08

23

BOLT,SOCKET HEAD

91314-06025-00

$6.68

24

PIN, DECOMPR .

1D7-12276-03-00

$27.97

25

CIRCLIP

93430-04055-00

$3.80

26

. WASHER, PLATE

90201-05M04-00

$2.39

27

SPRING, DECOMPRESSION

1D7-12287-00-00

$1.37

28

DECOMPRESSION ASSY

1D7-12280-00-00

$144.82

29

PIN, DECOMPR .

1D7-12276-03-00

$27.97

30

CIRCLIP

93430-04055-00

$3.80

31

. WASHER, PLATE

90201-05M04-00

$2.39

32

SPRING, DECOMPRESSION

1D7-12287-00-00

$1.37

33

DECOMPRESSION ASSY

1D7-12280-00-00

$144.82

Yamaha XV19CYCB (RAIDER CA) 29S5 2009 CAMSHAFT CHAIN Diagram
