1986 Yamaha XT600 CA (XT600SC) Starter Diagram

← All diagrams

Find the part on the Starter diagram for your 1986 Yamaha XT600 CA (XT600SC), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1986 Yamaha XT600 CA (XT600SC) Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

KICK CRANK ASSEMBLY

5Y1-15660-01-00

1
Out of stock

2

GEAR,KICK

34K-15641-00-00

1
Out of stock

3

WASHER, PLATE (2K7)

90201-20685-00

1

$5.69

In stock

4

CIRCLIP (525)

93410-20038-00

1

$2.62

In stock

5

WHEEL, RATCHET

5Y1-15671-01-00

—
Out of stock

6

SPRING COMPRESSION168156750000

90501-16107-00

—
Out of stock

7

WASHER, PLAIN (1JL)

90201-155K6-00

—
Out of stock

8

CIRCLIP(1AR)

99009-15400-00

1

$5.10

In stock

9

SPRING, TORSION

90508-32529-00

1
Out of stock

10

WASHER (566)

90201-15701-00

1

$6.17

In stock

11

STOPPER

2NX-15668-00-00

1
Out of stock

12

GUIDE, RATCHET WHEEL

2NX-15674-00-00

1

$8.71

In stock

13

WASHER, LOCK

214-15686-00-00

1

$6.38

In stock

14

BOLT, HEXAGON DEEP RECESS

97D95-06016-00

1

$1.91

In stock

15

STOPPER, KICK SPRING

248-15668-00-00

1
Out of stock

16

OIL SEAL (20X30X7-371)

93102-20108-00

—

$9.17

In stock

17

GEAR, SPR0CKET IDLE 31T

5Y1-15651-01-00

—
Out of stock

18

WASHER PLATE 328171160000

90201-20276-00

—
Out of stock

19

CIRCLIP(1AR)

99009-20400-00

—
Out of stock

20

KICK CRANK ASSY

5Y1-15620-02-00

—
Out of stock

21

BOSS, KICK CRANK

5Y1-15621-01-00

—
Out of stock

22

SPRING COMPRESSION278156220000

90501-12081-00

—
Out of stock

23

BALL (12R)

93507-32031-00

—
Out of stock

24

SCREW, COUNTERSUNK (5Y1)

90152-06010-00

—
Out of stock

25

. PLUG, TAPER

90336-18038-00

1
Out of stock

26

BOLT, HEXAGON

97013-08030-00

—

$3.20

In stock

27

LEVER DCOMP ASSEMBLY

3Y1-1561A-02-00

1
Out of stock

28

SEAL,OIL(SD 10-21-5 HS,3Y1)

93102-10207-00

—
Out of stock

29

WASHER, PLATE(52H)

90201-105J4-00

—

$6.88

In stock

30

CIRCLIP(10W)

99009-10400-00

—

$3.91

In stock

31

SPRING, TORSION

90508-14524-00

1
Out of stock

32

LEVER, CABLE

5Y1-1561G-00-00

—
Out of stock

33

WASHER, PLAIN (646)

92990-06600-00

—

$2.48

In stock

34

NUT(JN5)

95317-06700-00

—

$6.69

In stock
