Sea-doo XP DI, 2004 Air Intake Manifold Diagram

#

Description
Price

1

Was 415080100 Fuel Line Primer 3,2mm

219704409

Unavailable

2

CONNECTOR - Call your local BRP dealership

293710107

Unavailable

3

Air Silencer | Includes 18 to 21

273000209

Unavailable

4

Injector Ass'y

273000210

Unavailable

5

Was 415080100 Fuel Line Primer 3,2mm

219704409

Unavailable

6

CONNECTOR - Call your local BRP dealership

293710107

Unavailable

7

SUPPORT PLATE - Call your local BRP dealership

273000204

Unavailable

8

Cable Grommet

293720052

Unavailable

9

INTAKE ADAPTOR, PTO - Call your local BRP dealership

273000163

Unavailable

10

INTAKE ADAPTOR, MAG - Call your local BRP dealership

273000164

Unavailable

11

GROMMET - Call your local BRP dealership

293720064

Unavailable

12

CHECK VALVE - Call your local BRP dealership

275500454

Unavailable

13

Gasket

293250122

Unavailable

14

FEMALE ADAPTOR - Call your local BRP dealership

270600024

Unavailable

15

UPPER INSULATOR - Call your local BRP dealership

278001260

Unavailable

16

SPACER - Call your local BRP dealership

272000074

Unavailable

17

Hex. Screw M6 X 35

207063560

Unavailable

18

Flat Washer M6, Stainless

234062600

Unavailable

19

Flat Washer M6, Stainless

234062600

Unavailable

20

Hex. Elastic Stop Nut M6

232561600

Unavailable

21

PROTECTOR PAD - Call your local BRP dealership

273000165

Unavailable

22

HIGH AIR DUCT, PTO - Call your local BRP dealership

273000151

Unavailable

23

High Air Duct, Mag

273000150

Unavailable

24

HAIR PIN - Call your local BRP dealership

250400015

Unavailable

25

HEX. SCREW M8 X 12 - Call your local BRP dealership

207181260

Unavailable

26

Loctite 243, 10 ml

293800060

Unavailable

27

Flat Washer 8 mm, Stainless

234082600

Unavailable

28

AIR SILENCER ADAPTOR - Call your local BRP dealership

270600023

Unavailable

29

Hex. Screw M4 X 12, Scotch Grip

207341260

Unavailable

30

Flat Washer 4 mm, Stainless

234042600

Unavailable

31

INTAKE HOSE - Call your local BRP dealership

270600021

Unavailable

32

Tubing 25 MM 1000MM Long

219704402

Unavailable

33

Tie Wrap 142 mm

293750002

Unavailable

34

Tridon Gear Clamp

293650172

Unavailable

35

Tridon Gear Clamp

293650173

Unavailable

36

HOSE 4.3 MM - Call your local BRP dealership

270000471

Unavailable

37

Oetiker Clamp

293650100

Unavailable

38

HOSE 4.3 MM - Call your local BRP dealership

270000471

Unavailable

39

Oetiker Clamp

293650100

Unavailable

40

Tie Wrap 94 mm | 4X4

293750001

Unavailable

41

T-Fitting

293710068

Unavailable

42

HOSE 4.3 MM - Call your local BRP dealership

270000471

Unavailable

43

Oetiker Clamp

293650100

Unavailable

44

HOSE 4.3 MM - Call your local BRP dealership

270000471

Unavailable

45

Relay Support

291001945

Unavailable

46

Pop Rivet 3/16"

293150080

Unavailable

47

SOLENOID VALVE - Call your local BRP dealership

270600044

Unavailable

48

Hex. Screw M5 X 16, Scotch Grip

207351660

Unavailable

49

Flat Washer M5, Stainless

234051600

Unavailable

50

Was 420660574 Pressure Hose 280 mm

219704352

Unavailable

51

Tie Wrap 94 mm | 4X4

293750001

Unavailable

52

T-Fitting

293710068

Unavailable

53

Was 420660574 Pressure Hose 280 mm

219704352

Unavailable

54

Tie Wrap 94 mm | 4X4

293750001

Unavailable

55

Check Valve

275500398

Unavailable

56

Was 420660574 Pressure Hose 280 mm

219704352

Unavailable

57

Tubing 10 MM 1000MM Long

219704407

Unavailable

58

Tie Wrap 94 mm | 4X4

293750001

Unavailable

59

Tie Wrap 94 mm | 4X4

293750001

Unavailable

60

Was 420660574 Pressure Hose 280 mm

219704352

Unavailable

61

Tie Wrap 94 mm | 4X4

293750001

Unavailable

62

Tie Wrap 94 mm | 4X4

293750001

Unavailable

63

Tie-Rap 180 mm

414115200

Unavailable

64

Tubing 10 MM 1000MM Long

219704407

Unavailable

65

Tie Wrap 94 mm | 4X4

293750001

Unavailable
