Yamaha WB700R (WAVE BLASTER) 1993 HULL - DECK Diagram

#

Description
Price

1

JOINT, HOSE

61X-51162-00-00

$18.92

2

HOSE

90445-19M01-00

Unavailable

3

HOSE

90445-19M01-00

Unavailable

4

CLAMP

90465-10098-00

$1.68

5

PIPE 1

62E-51673-00-00

$24.98

6

HOSE (L380)

90445-14M25-00

$18.17

7

CLAMP

90465-10098-00

$1.68

8

HOSE

90446-20M39-00

Unavailable

9

SPOUT

FN8-6269B-00-00

$22.49

10

NUT

EU0-61652-00-00

$11.48

11

CLAMP

90465-10098-00

$1.68

12

STRAINER, BILGE

GD0-6761D-00-00

$58.99

13

BASE, STRAINER BLIGE

EW2-67618-00-00

$37.49

14

SCREW, PANHEAD TAPPING (682)

97780-50514-00

$3.57

15

CLAMP

90465-10098-00

$1.68

16

BAND (EU0)

90601-20009-00

$6.36

17

CONNECTION, THRU-HULL 1/4

90604-80759-00

$18.92

18

CONNECTION, THROUGH HALL (GD0)

90604-80775-00

Unavailable

19

GASKET

90430-13909-00

Unavailable

20

CLAMP

90465-10098-00

$1.68

21

DRAIN PLUG ASSY

EU0-62280-00-00

$28.23

22

. PLUG, DRAIN

EU0-62282-00-00

$7.40

23

. O-RING

EU0-62283-00-00

$3.70

24

. PACKING DRAIN (EU0)

EU0-62285-01-00

$5.91

25

SCREW, TAPPING

97780-50620-00

$2.75

26

. WASHER, PLAIN

92990-05200-00

$4.29

27

BOWEYE 1

FN8-U1624-00-00

Unavailable

28

WASHER, PLAIN

92990-08200-00

$2.36

29

. NUT, SELF-LOCKING

95720-08300-00

$3.33
