Suzuki VZ800L2 (2012) CRANKSHAFT Diagram

#

Description
Price

1

CRANKSHAFT SET This part replaces 12000-41810.

12000-41830

$1,481.32

2

WASHER (48.1X64X1.94)

09160-48001

Unavailable

2

WASHER (48.1X64X1.96)

09160-48002

Unavailable

2

WASHER (48.1X64X1.99)

09160-48003

Unavailable

2

WASHER (48.1X64X2.01)

09160-48004

Unavailable

2

WASHER (48.1X64X2.04)

09160-48005

Unavailable

2

WASHER (48.1X64X2.06)

09160-48006

$32.98

2

WASHER (48.1X64X2.09)

09160-48007

Unavailable

2

WASHER (48.1X64X2.11)

09160-48008

Unavailable

2

WASHER (48.1X64X2.14)

09160-48009

Unavailable

2

WASHER (48.1X64X2.16)

09160-48010

$32.98

3

BEARING, CRANKSHAFT

12229-39G00-0A0

$19.52

3

BEARING, CRANKSHAFT

12229-39G00-0B0

$19.52

3

BEARING, CRANKSHAFT

12229-39G00-0C0

$19.52

4

WASHER, CRANK THRUST

12652-38A00

$92.23

5

ROD ASSY, CONNECTING

12160-45C30

$207.97

6

NUT

09159-09001

$5.10

7

BEARING, CRANK PIN (GREEN)

12164-38E00-0A0

$15.55

7

BEARING, CRANK PIN (BLACK)

12164-38E00-0B0

$10.83

7

BEARING, CRANK PIN (BROWN)

12164-38E00-0C0

$10.83

7

BEARING, CRANK PIN (YELLOW)

12164-38E00-0D0

$15.83

7

BEARING, CRANK PIN (BLUE)

12164-38E00-0E0

$15.83

8

PISTON This part replaces 12111-41F00-0F0.

12111-41F10-0F0

$136.22

9

RING SET, PISTON

12140-41F00

$40.00

10

PIN,PISTON

12151-24A00

$20.17

11

CIRCLIP

09381-20004

$1.64

12

PISTON SET (OS:0.5) | OPT This part replaces 12100-41F00-050.

12100-41F10-050

$199.83

13

SPROCKET, CAM CHAIN DRIVE RH

12731-38A00

$66.67

14

GEAR, PRIMARY DRIVE | NT:42

21111-38A00

Unavailable

15

BOLT (12X28)

09103-12013

$9.60
