2005 Suzuki VZ1600 Chassis Electrical Equipment Diagram

← All diagrams

Find the part on the Chassis Electrical Equipment diagram for your 2005 Suzuki VZ1600, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2005 Suzuki VZ1600 Chassis Electrical Equipment Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

14091

COVER,CONNECTOR

K1409-10236

1
Out of stock

21061

RECTIFIER

K2106-11003

2
Out of stock

26006

FUSE,30A-G

K2600-61006

1
Out of stock

26006A

FUSE,10A-R

K2600-61007

7
Out of stock

26006B

FUSE,15A-B

K2600-61061

3
Out of stock

26011

WIRE-LEAD,BATTERY(+)

K2601-10018

1
Out of stock

26011A

WIRE-LEAD,BATTERY(-)

K2601-11750

1
Out of stock

26012

BATTERY ASSY This part replaces K2601-21371.

33610-03G10

1
Out of stock

26021

JUNCTION BOX

K2602-10002

1
Out of stock

26030

HARNESS,SUB

K2603-01450

1
Out of stock

26031

HARNESS,MAIN

K2603-10228

1
Out of stock

27002

RELAY-ASSY

K2700-21051

1
Out of stock

27002A

RELAY-ASSY,SIGNAL LAMP

K2700-21113

1
Out of stock

27003

HORN

K2700-31431

1
Out of stock

49016

COVER-SEAL,FUSE

K4901-60005

1
Out of stock

92037

CLAMP,L=60

K9203-71069

1
Out of stock

92037A

CLAMP

K9203-71173

1
Out of stock

92160

DAMPER,JUNCTION BOX

K9216-01650

1
Out of stock

92171

CLAMP,IGNITION COIL,LH

K9217-10204

1
Out of stock

92171A

CLAMP,COUPLER

K9217-10231

1
Out of stock

92171B

CLAMP,HARNESS

K9217-11269

1
Out of stock

92171C

CLAMP,IGNITION COIL,RH

K9217-11370

1
Out of stock

92171D

CLAMP,DIA=13

K9217-11415

1
Out of stock

92171E

CLAMP,DIA=10

K9217-11423

2
Out of stock

92171F

CLAMP,DIA=15

K9217-11424

10
Out of stock

130

BOLT-FLANGED

KK130-J0612

2
Out of stock

130A

BOLT-FLANGED,6X10

KK130-V0610

1
Out of stock
