Primary Sheave
1997 Yamaha Vmax 600 XTC (Reverse) (VX600XTCRA) Primary Sheave Diagram
Find the part on the Primary Sheave diagram for your 1997 Yamaha Vmax 600 XTC (Reverse) (VX600XTCRA), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.
#
Description
Qty in Assembly
Price
Status
Order Qty
8
SPIDER COMP.
8CA-17640-12-00
1
Out of stock
18
WASHER, PLATE(8BV)
90202-09227-00
—
Out of stock
19
ROLLER, COMP
8CR-17624-20-00
—
Out of stock
20
ROLLER BUSH
90380-09239-00
1
Out of stock
21
WASHER, PLATE(88R)
90202-08204-00
—
Out of stock
23
. BUSH, SOLID
90380-08244-00
1
Out of stock
24
RIVET, COUNTER SUNK (8G8)
90261-06017-00
—
Out of stock
26
V-BELT
89L-17641-02-00
1
Out of stock
26
V-BELT
89L-17641-02-00
1
Out of stock
