Sea-doo Utopia 185/205, 2002 Fuel System Diagram

#

Description
Price

1

Fuel Tank

204560220

Unavailable

Not Available As Spare Part - Friction Washer

Unavailable

2

FUEL TANK STRAP - Call your local BRP dealership

204560181

Unavailable

3

PROTECTOR PAD - Call your local BRP dealership

204560185

Unavailable

4

Fuel Tank Strap

204560184

Unavailable

5

Protector Pad

204560186

Unavailable

6

Hex. Screw M8 X 30

207183060

Unavailable

7

Lock Washer 8 mm, Stainless

234181601

Unavailable

8

Flat Washer 8 mm, Stainless

234082600

Unavailable

9

Loctite 271, 10 ml

293800005

Unavailable

10

HEX. SCREW M8 X 80 - Call your local BRP dealership

207188060

Unavailable

11

Hex. Elastic Nut M8

232581600

Unavailable

12

NEOPRENE PAD - Call your local BRP dealership

204560191

Unavailable

13

NORMA CLAMP - Call your local BRP dealership

293650069

Unavailable

14

T-Fitting

204560038

Unavailable

15

HOSE 16 MM - Call your local BRP dealership

204560358

Unavailable

16

NORMA CLAMP - Call your local BRP dealership

293650121

Unavailable

17

VENT FUEL SURGE PROTECTOR - Call your local BRP dealership

204560101

Unavailable

18

FILLER NECK - Call your local BRP dealership

204560182

Unavailable

19

SPACER - Call your local BRP dealership This part replaces 275500801.

204560188

Unavailable

20

Phillips Screw M4 X 35

208643560

Unavailable

21

Flat Washer 4 mm

234040600

Unavailable

22

Elastic Stop Nut M4

232541600

Unavailable

23

Filler Neck Hose

204560134

Unavailable

24

Norma Clamp

293650077

Unavailable

25

Hose 5/16”, Meter

204560177

Unavailable

26

NORMA CLAMP - Call your local BRP dealership

293650121

Unavailable

NORMA CLAMP - Call your local BRP dealership

293650070

Unavailable

27

NORMA CLAMP - Call your local BRP dealership

293650070

Unavailable

28

HOSE 1/4 - Call your local BRP dealership

204560178

Unavailable

29

Mount Dart

293730040

Unavailable

30

Tie-Rap 180 mm

414115200

Unavailable

Tie Wrap 368 mm

293750008

Unavailable

31

PROTECTOR PAD - Call your local BRP dealership

204560115

Unavailable

32

Black, Dart

293730006

Unavailable

33

RUBBER PAD - Call your local BRP dealership

204060684

Unavailable

34

Fuel Level Sensor

204560217

Unavailable

35

Rigid Pick-Up Tub

204560218

Unavailable

36

Anti-Siphon Valve

204560219

Unavailable
