1974 Suzuki TS50 Gear Shifting Diagram

← All diagrams

Find the part on the Gear Shifting diagram for your 1974 Suzuki TS50, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1974 Suzuki TS50 Gear Shifting Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

NO DESCRIPTION AVAILABLE This part replaces 25211-05100.

25211-05101

2
Out of stock

2

FORK, GEAR SHIFTING B

25221-05100

1
Out of stock

3

PIN, FORK GUIDE

09209-10002

2
Out of stock

4

ROLLER | 6x9.8x6 This part replaces 09180-06004.

09180-06086

3
Out of stock

5

2

$1.31

In stock

6

SHAFT, GEAR SHIFTING FORK

25411-05100

1
Out of stock

7

NO DESCRIPTION AVAILABLE This part replaces 25311-05600.

25311-05100

1
Out of stock

8

ROLLER (4X13.8) | OD:4, L:12

09261-04002

4
Out of stock

9

BOLT

09111-06004

1
Out of stock

10

NO DESCRIPTION AVAILABLE This part replaces 25340-05100.

25340-05101

1
Out of stock

11

SCREW This part replaces 02122-06168.

02122-06167

1
Out of stock

12

BOLT, REAR This part replaces 01112-06308.

01500-06307

1
Out of stock

13

1

$2.28

In stock

14

STOPPER, CAM

25350-05100

1
Out of stock

15

NO DESCRIPTION AVAILABLE This part replaces 25354-05100.

25354-05101

1
Out of stock

16

SPACER | 6x9x14x4

09180-06022

1
Out of stock

17

SPRING

09443-08005

1
Out of stock

18

.NUT This part replaces 08311-11068.

08310-00067

1
Out of stock

19

PLATE, STOPPER

25381-05100

1
Out of stock

20

SHAFT, GEAR SHIFTING

25510-26000

1
Out of stock

21

SPRING

09443-07013

1
Out of stock

22

SPRING

09444-26005

1
Out of stock

23

STOPPER

25671-19000

1
Out of stock

24

LOCK WASHER This part replaces 08321-21108.

08321-01107

1
Out of stock

25

OIL SEAL (12X22X9) | 12X22X9 This part replaces 09285-12002.

09285-12006

1
Out of stock

26

SWITCH, NEUTRAL INDICATOR

37721-26000

1
Out of stock

27

GASKET

37712-26000

1
Out of stock

28

SCREW This part replaces 02111-03048.

02112-03047

1
Out of stock

29

WASHER This part replaces 08322-21038.

08322-01037

1
Out of stock

30

CONTACT, SWITCH This part replaces 37711-05100.

37711-05101

1
Out of stock

31

SCREW This part replaces 02122-06128.

02122-06127

1
Out of stock

32

SCREW This part replaces 02111-04207.

02112-0420A

2
Out of stock

33

LOCK WASHER | E.NO. 58969~ This part replaces 08321-21048.

08321-0104A

2
Out of stock

34

WASHER | E.NO. 58969~ This part replaces 08322-21048.

08322-01047

2
Out of stock

35

LEVER, GEAR SHI | Includes Item(s) 36 This part replaces 25600-25101.

25600-39101

1
Out of stock

36

.RUBBER,GEAR SHIFT PEDAL This part replaces 25652-16500.

25652-16510

1
Out of stock

37

.RUBBER,GEAR SHIFT PEDAL This part replaces 25652-03201.

25652-16510

1
Out of stock

38

BOLT This part replaces 01112-06208.

01500-06207

1
Out of stock

39

1

$2.28

In stock
