Suzuki TS250 (1981) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

CASE ASSY,THROT | Includes Item(s) 2 - 4 This part replaces 57100-30900.

57100-30940

$90.88

2

CASE ASSY,THROT This part replaces 57100-30930.

57100-30940

$90.88

3

GRIP, THROTTLE

57110-30900

$41.93

4

SCREW This part replaces 02112-05258.

02112-05257

$1.55

5

LEVER ASSY, BRAKE | Includes Item(s) 6 - 18

57300-37100

Unavailable

6

LEVER, BRAKE

57420-26500

$31.87

7

BOLT This part replaces 57431-11011.

57431-11013

$6.21

8

.NUT This part replaces 08319-21068.

08319-2106A

$1.97

9

ADJUSTER, CABLE

57441-11010

$5.38

10

NUT

57442-11010

$2.80

11

BOLT This part replaces 01107-06208.

01500-06207

$2.06

12

HOLDER This part replaces 57461-18600.

57465-18601

$4.15

13

HOLDER This part replaces 57462-18600.

57465-18601

$4.15

14

HOLDER This part replaces 57463-18600.

57465-18601

$4.15

15

COVER

57481-33010

$5.74

16

WASHER This part replaces 08322-21038.

08322-01037

$2.01

17

WASHER,LOCK This part replaces 08321-21038.

09162-03001

$1.22

18

SCREW This part replaces 09125-03105.

09125-03105-XC0

$2.08

19

COVER, CLUTCH LEVER This part replaces 57341-40001.

57341-40003

$5.24

20

BAND (L:120)

09407-12402

$2.82
