Ski-Doo Touring 380 F/500F, 2001 Front Arm Diagram

#

Description
Price

1

Grease Fitting

408200700

Unavailable

2

Washer

732900049

Unavailable

3

Rear Shock | Touring 380 F.

503188902

Unavailable

Rear Shock | Touring 500 F.

503188907

Unavailable

4

Rear Shock (HPG) (Europe)

503189570

Unavailable

5

HPG Decal (Europe)

516000182

Unavailable

6

Bushing

414936000

Unavailable

7

Hex. Screw M8 X 40

207084044

Unavailable

8

Hex. Elastic Stop Nut M8

232581414

Unavailable

9

Shock Support

503189466

Unavailable

10

Welded Front Arm

503189311

Unavailable

11

HEX. SCREW M12 X 60, SCOTCH GRIP - Call your local BRP dealership

207226044

Unavailable

12

Washer

503189276

Unavailable

13

SHAFT - Call your local BRP dealership

503189313

Unavailable

14

SHAFT - Call your local BRP dealership

503190387

Unavailable

15

Bushing

503189324

$11.17

16

CUSHION - Call your local BRP dealership

503189323

Unavailable

17

Hex. Screw M10 X 55, Scotch Grip | RT

207205544

Unavailable

18

SHOCK - Call your local BRP dealership

503189331

Unavailable

Shock

503188903

Unavailable

19

WASHER - Call your local BRP dealership

505070401

Unavailable

WASHER - Call your local BRP dealership

503184400

$2.75

20

Spring | Touring 500 F.

415103600

Unavailable

Spring

415069900

Unavailable

21

Protector

503193663

Unavailable

22

GUIDE_SPRING - Call your local BRP dealership

503165100

$1.91

Spring Guide

503187500

Unavailable

23

Spring Stopper

706200881

$10.30

24

Axle

503151600

$15.35

25

HEX. SCREW M8 X 30, SCOTCH GRIP - Call your local BRP dealership

207383044

Unavailable

26

Washer

503189157

$3.20

27

STOPPER STRAP - Call your local BRP dealership

503190782

Unavailable

28

Hex. Screw M8 X 25

207182544

Unavailable

29

Flat Washer

224081301

$0.86

30

SYNTHETIC GREASE, 400 G - Call your local BRP dealership

219700417

Unavailable
