Kawasaki TERYX4™ Door Diagram

#

Description
Price

14092

COVER,SIDE GUARD,FR,LH,B.WHITE

14092-0748-266

$229.99

14092A

COVER,SIDE GUARD,FR,LH,S.BLACK

14092-0748-839

$219.72

14092B

COVER,SIDE GUARD,FR,RH,B.WHITE

14092-0749-266

$229.99

14092C

COVER,SIDE GUARD,FR,RH,S.BLACK

14092-0749-839

$192.03

14092D

COVER,SIDE GUARD,RR,LH,B.WHITE

14092-0751-266

$152.90

14092E

COVER,SIDE GUARD,RR,LH,S.BLACK

14092-0751-839

$146.11

14092F

COVER,SIDE GUARD,RR,RH,B.WHITE

14092-0752-266

$152.90

14092G

COVER,SIDE GUARD,RR,RH,S.BLACK

14092-0752-839

$146.11

27012

HOOK

27012-0705

$7.39

46001

HANDLE-ASSY,SIDE GUARD,LH

46001-0556

$77.60

46001A

HANDLE-ASSY,SIDE GUARD,RH

46001-0557

$77.60

53009

HINGE

53009-0303

$4.77

55020

GUARD,SIDE,FR,LH

55020-0737

$136.06

55020A

GUARD,SIDE,FR,RH

55020-0738

$136.06

55020B

GUARD,SIDE,RR,LH

55020-0739

$136.06

55020C

GUARD,SIDE,RR,RH

55020-0740

$136.06

92033

RING-SNAP

92033-0719

$0.73

92039

RIVET,4.0X17.5

92039-0703

$0.84

92039A

RIVET,5X23.3

92039-0769

$1.36

92043

PIN,6X56

92043-0743

$3.13

92139

BUSHING,6X8X6

92139-0709

$2.09

92154

BOLT,TORX,8X13

92154-1911

$0.84

92161

DAMPER,9X28X24.3

92161-1456

$2.80

92172

SCREW,6X16

92172-0711

$2.11

92210

NUT,CAP,6MM

92210-0003

$0.60

92210A

NUT,TORX,8MM

92210-1442

$2.75

411

WASHER-PLAIN,6MM

411AB0600

$0.95
