1973 Yamaha SW433C Secondary Sheave Diagram

← All diagrams

Find the part on the Secondary Sheave diagram for your 1973 Yamaha SW433C, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1973 Yamaha SW433C Secondary Sheave Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

SEC FXD SHV

(826-17660-00-00)

1
Out of stock

2

SEC SLIDING SHEAVE

(810-17670-00-00)

1
Out of stock

3

SHAFT, SECONDARY

826-17681-00-00

1
Out of stock

4

PIN, SPRING TYPE

90254-08001-00

1
Out of stock

5

SPRING, SECONDARY (805-17683-00)

805-17683-00-00

1
Out of stock

6

SEAT, SEC SPRINGSPRING

810-17684-01-00

1
Out of stock

7

SHOE, RAMP

801-17688-10-00

1

$4.15

In stock
← Rear Axle Track - Suspension Wheel →
