Suzuki SV650 (2007) RADIATOR HOSE Diagram

#

Description
Price

1

CAP, RADIATOR 1.1 | SV650K3/K4 MODEL K5/K6/K7

17730-19D11

$38.74

1

CAP, RADIATOR | SV650SK3/SK4 This part replaces 17730-12C20.

17730-08J00

$38.90

2

SCREW,RADIATOR CAP | SV650K3/K4 MODEL K5/K6/K7

17733-03D10

$2.97

3

HOSE, RADIATOR INLET | MODEL K3/K4

17851-17G00

$39.85

3

HOSE, RADIATOR INLET | MODEL K5/K6/K7

17851-17G10

$39.85

4

HOSE, RADIATOR OUTLET | MODEL K3/K4

17852-17G00

$35.60

4

HOSE, RADIATOR OUTLET | MODEL K5/K6

17852-17G10

$36.98

4

HOSE, RADIATOR OUTLET | MODEL K7

17852-17G20

$36.28

5

CLAMP

09402-38511

$10.69

6

HOSE,CONNECTOR INLET

17853-19F00

$13.50

7

UNION, CONNECTOR HOSE | MODEL K3 This part replaces 17890-06G00.

17890-06G20

$13.59

7

UNION, CONNECTOR HOSE | MODEL K4/K5/K6/K7

17890-06G20

$13.59

8

O RING

09280-18009

$5.26

9

BOLT This part replaces 07130-06123.

07130-0612A

$2.50

10

TANK ASSY, RESERVOIR | MODEL K3/K4/K5/K6

17910-17G00

Unavailable

10

TANK ASSY, RESERVOIR | MODEL K7; Includes Item(s) 11

17910-17G10

Unavailable

11

.CAP,RESERVOIR TANK

17931-02FA0

$5.09

12

BOLT

09111-06085

$4.16

13

HOSE, RESERVOIR TANK INLET

09352-50901-600

$7.37

14

HOSE, RESERVOIR TANK OVERFLOW, NO.1 | L:600!400

09352-50901-600

$7.37

15

HOSE(7X10.2X600 | L:600!380 This part replaces 09352-70103-600.

09352-70104-600

$5.07

16

JOINT

09367-08005

$5.25

17

CLIP

09401-08411

$1.77

18

BRACKET, RESERVOIR TANK | MODEL K3/K4/K5/K6

17920-17G00

Unavailable

18

BRACKET, RESERVOIR TANK | MODEL K7

17920-17G10

Unavailable

19

BOLT | MODEL K3/K4/K5/K6 This part replaces 01550-06103.

01550-0610A

$1.97

19

BOLT | MODEL K7

01550-0610A

$1.97

20

SWITCH COMP,FAN | Includes Item(s) 21 This part replaces 17680-50F10.

17680-50F11

$88.25

21

O RING

17689-50F00

$2.63

22

CONNECTOR,THERMOSTAT INLET

17662-02F11

$72.57

23

CAP,THERMOSTAT CONNECTOR

17663-17G00

$33.12

24

THERMOSTAT,WATER This part replaces 17670-06G50.

17670-06G51

$23.59

25

BOLT This part replaces 01550-06163.

01550-0616A

$1.97

26

HOSE, CONNECTOR TO WATER PUMP

17856-19F00

$19.32

27

CLIP This part replaces 09401-12409.

09401-12414

$2.98

28

SENSOR, WATER TEMPERATURE

13650-57F00

$136.53

29

GASKET

09168-12017

$1.97

30

CLAMP | SV650K3/K4 MODEL K5/K6/K7

09402-28511

$6.21

30

CLAMP | SV650SK3/SK4

09402-28511

$6.21

31

HOSE, CONDUCTION | SV650SK3/SK4

17855-17G00

Unavailable

32

CONDUCTION, RADIATOR | SV650SK3/SK4

17791-24D00

$69.02

33

BRACKET, CONDUCTION | SV650SK3/SK4

17790-17G10

Unavailable

34

BOLT, CLAMP | SV650SK3/SK4 This part replaces 01550-06123.

01550-0612A

$1.97

35

BOLT | SV650SK3/SK4 This part replaces 01550-06103.

01550-0610A

$1.97
