Description

Price

1

GEAR ASSY, PRIMARY DRIVEN | SV1000K3/SK3/SK4

21200-16810

$608.33

1

GEAR ASSY, PRIMARY DRIVEN | SV1000SK5

21200-16820

$597.08

2

WASHER (25X52X2.5)

09160-25074

$10.00

3

BEARING (35X40X39.8)

09263-35013

$32.08

4

HUB, CLUTCH SLEEVE

21410-16G00

Unavailable

5

CAM SET, CLUTCH

21610-02F20

$277.12

6

BOLT, SPRING SUPPORT | MODEL K3/K4 This part replaces 21481-02F11.

21481-02F12

$7.04

6

BOLT, SPRING SUPPORT | MODEL K5

21481-02F12

$7.04

7

SPRING, CLUTCH

21413-16G00

$9.17

8

BOLT, CLUTCH SPRING | MODEL K3/K4 This part replaces 21482-02F11.

21482-02F12

$2.80

8

BOLT, CLUTCH SPRING | MODEL K5

21482-02F12

$2.80

9

PLATE, CLUTCH DRIVE, NO.1 | T:3.0

21441-24F30

$31.90

10

PLATE, CLUTCH DRIVE, NO.2 | T:3.8

21441-24F10

$21.99

11

.PLATE,CLUTCH DRIVEN NO.1 (T: | T:2.0

21451-24F00

$10.61

12

PLATE, CLUTCH DRIVEN NO.2 | T:2.3

21451-24F10

$10.61

13

PLATE, CLUTCH DRIVE NO.3 | T:3.8

21442-24F00

$22.11

14

.SEAT,WAVE WASHER

21471-24F00

$13.05

15

WASHER,CLUTCH PLATE WAVE

21472-06G00

$21.28

16

DISK, CLUTCH PRESSURE

21462-16G00

$76.32

17

NUT, CLUTCH SLEEVE HUB

09159-24010

$11.92

18

WASHER (25X50X5.8)

09160-25076

$20.22

19

WASHER (24.2X35X2)

09164-24006

$3.38

20

ROD, CLUTCH PUSH, RH

23110-27A00

$19.86

21

ROD, CLUTCH PUSH, LH

23111-26D00

$14.54

22

PIECE, CLUTCH PUSH

23121-31E00

$22.52

23

CYLINDER,CLUTCH RELEASE | MODEL K3 This part replaces 23160-06G00.

23160-06G21

$97.71

23

CYLINDER,CLUTCH RELEASE | MODEL K4/K5; Includes Item(s) 24 - 28 This part replaces 23160-06G01.

23160-06G21

$97.71

24

CUP

23163-06B00

$6.61

25

SPRING

23164-05A00

$3.97

26

COVER, DUST

23166-02F20

$11.66

27

BLEEDER

59121-01A00

$7.99

28

CAP, BLEEDER

59122-01A00

$3.97

29

PIN, CL RLSE CYL

04221-08149

$1.98

30

BOLT This part replaces 07130-06653.

07130-0665B

$3.47

31

BOLT This part replaces 07130-06703.

07130-0670B

$3.52

32

WASHER, CLUTCH PUSH | 15.5X28X1

09160-15045
