Ski-Doo Summit X 600 H.O. E-TEC, 2009 Front Arm Diagram

#

Description
Price

1

STOPPER STRAP - Call your local BRP dealership

503191857

Unavailable

2

Hex. Flange Screw M8 X 30 | DS 650 X

207683044

$1.30

3

Flat Washer

224081301

$0.86

4

Hex. Flange Elastic Nut M8

233281414

$1.14

5

Axle Strap

503191260

$29.20

6

Spacer

503191448

$10.20

7

Socket Head Screw M10 X 35, Scotch Grip

205503544

$1.39

8

Washer

503189564

$0.72

9

Rocker

503192211

$78.43

10

Bushing

503193037

$15.35

11

Bushing | Includes 240d to 240d1

503189282

$4.18

12

Hex. Screw M10 X 1.5 X 50

207005044

$3.11

13

Elastic Stop Nut M10

232500416

$1.56

14

Not Available As Spare Parts

XXX

Unavailable

15

Axle Strap

503191260

$29.20

16

Socket Head Screw M10 X 35, Scotch Grip

205503544

$1.39

17

Washer

503189564

$0.72

18

Not Available As Spare Parts

XXX

Unavailable

19

Not Available As Spare Parts

XXX

Unavailable

20

Not Available As Spare Parts

XXX

Unavailable

21

FRONT ARM ASS'Y - Call your local BRP dealership | Includes 17 to 19

503191580

Unavailable

22

Extended Bushing

503191556

$5.71

23

Grease Fitting

408200700

$2.80

24

Lower Shaft

503191279

$27.66

25

Bushing

503189324

$11.17

26

Washer

503189564

$0.72

27

HEX. SCREW M10 X 55, SCOTCH GRIP - Call your local BRP dealership

207205586

Unavailable

28

Upper Shaft

503191215

$36.12

29

Bushing

503191262

$13.60

30

Washer

503189564

$0.72

31

HEX. SCREW M10 X 55, SCOTCH GRIP - Call your local BRP dealership

207205586

Unavailable

32

ROD_LINK - Call your local BRP dealership

503191148

Unavailable

33

Swivel Bushing

503191555

$5.71

34

Axle Bar (Long)

503190643

$15.35

35

Hex. Flange Screw

207688544

$1.68

36

Hex. Flange Elastic Nut M8

233281414

$1.14

37

Bushing

414936000

$11.55

38

Hex. Flange Screw M8 X 40

207684044

$1.25

39

Hex. Flange Elastic Nut M8

233281414

$1.14

40

Hex. Screw M10 X 1.5 X 50

207005044

$3.11

41

Elastic Stop Nut M10

232500416

$1.56

42

CENTER SHOCK SHAFT - Call your local BRP dealership This part replaces 503191258.

503189272

Unavailable

43

Center Bushing

503191259

$8.97

44

Washer

503189276

$3.20

45

Socket Head Screw M12 X 35, Scotch Grip

205523544

$2.91

46

SYNTHETIC GREASE, 400 G - Call your local BRP dealership

219700417

Unavailable
