Ski-Doo Summit Sport 800RPTEK XP154, 2015 Steering _23M1516 Diagram

#

Description
Price

3

Hex. Screw M10 X 1.5 X 40

207004034

$1.74

5

Hex Screw M10 X 1.5 X 55

207005554

$6.18

6

Hex. Flange Screw M6 X 70

207667056

$3.61

8

Clamps | Includes 75a to 75b

719000049

$23.05

9

Elastic Flange Nut M6 X 1.0

233261416

Unavailable

11

Hex. Flange Screw M8 X 40

250000352

Unavailable

12

Torx Screw M6 X 1.0 X 18, Scotch Grip

250000779

Unavailable

13

Hex. Flange Screw M6 X 25

250000447

$2.06

14

LH Threaded Hex. Jam Nut M10

250100016

Unavailable

16

Plate

506152163

$10.23

17

Lower Half-Housing

506152217

$5.57

18

Housing Bushing

506152297

Unavailable

21

Not Available As Spare Parts

XXX

Unavailable

23

Moulding Strap

506152460

$69.99

25

Tie-Rod

506152482

Unavailable

26

Upper Half-Housing

506152508

$7.40

27

Upper Anti-Vibration Gasket

506152509

$4.52

28

Lower Vibration Ring

506152518

Unavailable

29

Bushing

506152521

$13.60

30

Deep Black, Steering Pad

506152541

$42.28

31

Isolant

506152611

$7.80

32

Grip

506152486

$14.71

34

Extension Kit ( 205mm ) This part replaces 860200269.

860200821

Unavailable

35

Steering Column

506152962

$189.20

40

Heating Element 28 WATT This part replaces 506152602.

506152603

$43.82

42

Black Support Plate

506152703

Unavailable

43

Handle Bar, Non Dyed Clear Anodizing

506152709

$81.51

46

Steering Support | Includes 40 to 40a

506152751

$10.09

48

LOW TEMPERATURE TUBING 1/2? 3000MM LONG - Call your local BRP dealership

219704427

Unavailable

50

RH Threaded Hex. Jam Nut M10

732610010

Unavailable

51

Steering Support | Includes 40 to 40a

506152751

$10.09

52

Elastic Locking Nut M10

233601466

Unavailable

53

Washer

506152582

Unavailable

54

Hex. Flange Elastic M10 x 1.5

233201464

Unavailable

70

LH Thread Ball Joint

506152081

$39.97

71

RH Threaded Ball Joint

506152019

$39.97
