Ski-Doo Summit 600 HO, 2005 Seat Diagram
#
Description
Price
1
Not Available As Spare Part - Friction Washer
Unavailable
2
SEAT BASE ASS'Y - Call your local BRP dealership
510004582
Unavailable
3
Not Available As Spare Part - Friction Washer
Unavailable
4
Seat Base Ass'y
510004214
Unavailable
7
NUT HOUSING ASS'Y M6 - Call your local BRP dealership | Includes 2 To 3
708000046
Unavailable
8
M6 Nut Housing Ass'y | Includes 290 to 290b
269500252
Unavailable
9
Hex. Nut M6
232061600
Unavailable
10
Seat Cover
510004215
Unavailable
11
Foam
510004351
Unavailable
12
Deep Black, Trunk
510004213
Unavailable
12
Labrador Blue, Trunk
510004532
Unavailable
13
Torx Truss Screw M6 X 16
250000721
Unavailable
14
Torx Screw M6 X 20
250000722
Unavailable
15
Torx Truss Screw M6 X 16
250000721
Unavailable
