Description

Price

11047

BRACKET,HANDLE HOLDER

11047-3759

$110.16

11056

BRACKET,HANDLE POLE BRACKET

11056-3712

$16.15

11056A

BRACKET

11056-3713

$9.98

11061

GASKET,HANDLE POLE BRACKET

11061-3739

$31.07

13107

SHAFT

13107-1600

$60.56

13270

PLATE,STEERING NUT

13270-3808

$7.58

13280

HOLDER

13280-1374

$54.46

13320

LEVER-ASSY,REVERSE

13320-0047

$47.79

39021

BRACKET-HANDLE POLE

39021-3716

$331.57

39117

SHAFT-STRG

39117-0018

$339.45

59266

JOINT-BALL

59266-3707

$59.33

92015

NUT,CASTLE,14MM

92015-3805

$36.18

92022

WASHER,15X34X2.0

92022-3738

$4.93

92022A

WASHER,8.4X23X2.5

92022-3744

$3.19

92028

BUSHING,STEERING

92028-3748

$24.03

92152

COLLAR

92152-3748

$1.56

92153

BOLT,SOCKET,8X25

92153-3739

$3.36

92171

CLAMP,L=150

92171-3717

$7.61

92200

WASHER,32.5X70X2

92200-3718

$15.76

92200A

WASHER,16.5X25X1

92200-3800

$1.85

92210

NUT,STEERING SHAFT,22MM

92210-3800

$98.23

120

BOLT-SOCKET,5X10

120R0510

$3.01

120A

BOLT-SOCKET,6X20

120R0620

$2.74

317

NUT

317R0800

$1.42

550

PIN-COTTER,3X35

550S3035

$4.02

Kawasaki STX 160X Handle Pole Diagram
