Kawasaki STX-15F Cooling Diagram

#

Description
Price

13091

HOLDER

13091-3712

$4.14

14091

COVER,INSIDE

14091-3755

$87.33

14091A

COVER,OUTSIDE

14091-3756

$87.33

27010

SWITCH,OIL PRESSURE

27010-3779

$60.66

39067

COOLER-OIL

39067-3704

$265.22

59071

JOINT

59071-3764

$7.51

92005

FITTING

92005-3714

$14.12

92005A

FITTING,FLUSH

92005-3744

$12.85

92005B

FITTING,FLUSH

92005-3748

$9.34

92055

RING-O,58X3

92055-3767

$4.65

92055A

RING-O

92055-3770

$17.77

92055B

RING-O

92055-3772

$9.92

92066

PLUG,FLUSH

92066-3784

Unavailable

92071

GROMMET

92071-3815

$4.14

92072

BAND,L=188

92072-1239

$1.30

92072A

BAND,L=99

92072-3871

$1.95

92072B

BAND,L=152

92072-3874

$3.75

92153

BOLT,OIL COOLER

92153-3713

$25.83

92161

DAMPER

92161-1331

$2.63

92170

CLAMP

92170-3747

$10.33

92171

CLAMP

92171-3714

$7.22

92191

TUBE,PUMP-HULL

92191-3785

$24.29

92191A

TUBE,CHAMBER-TAIL PIPE

92191-3850

$78.22

92191B

TUBE,7X12X1590

92191-3874

Unavailable

92191C

TUBE,CORRUGATED,19.5X23.8X500

92191-3884

$3.51

92192

TUBE,CORRUGATED,19.5X23.8X900

92192-3711

$4.75

92192A

TUBE,CORRUGATED,19.5X23.8X380

92192-3714

$2.19

92192B

TUBE,12X18X630

92192-3716

$56.99

92192C

TUBE,CORRUGATED,19.5X23.8X1400

92192-3732

$7.64

92192D

TUBE,GENERATOR-HULL

92192-3739

$55.68

92192E

TUBE,12X18X1000

92192-3740

$24.75

92192F

TUBE,12X18X1520

92192-3741

$35.92

92192G

TUBE,12X18X480

92192-3742

$12.61

92192H

TUBE,12X18X450

92192-3745

$12.61

92192I

TUBE,WATER MUFFLER-HULL

92192-3746

$56.31

130

BOLT-FLANGED,8X50

130Y0850

Unavailable

132

BOLT-FLANGED-SMALL,6X20

132Y0620

Unavailable

670

O RING,14MM

670D2014

$4.18
