1977 Yamaha SRX440A Water Temperature Diagram

← All diagrams

Find the part on the Water Temperature diagram for your 1977 Yamaha SRX440A, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1977 Yamaha SRX440A Water Temperature Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

WATER TEMP METER

(8A7-83590-00-00)

1
Out of stock

1

TOOL

UNA-VAILA-BL-EI

1
Out of stock

2

STAY, METER

8A7-12467-00-00

1
Out of stock

3

O-RING

93210-56077-00

1
Out of stock

4

CLIP

90468-10001-00

1
Out of stock

5

JOINT

8A7-12446-01-00

1
Out of stock

6

CLIP(3BM)

90467-10135-00

1

$6.91

In stock

7

WASHER

8A7-12456-00-00

1
Out of stock

8

SCREW, BINDING

98907-06016-00

1

$7.14

In stock

9

WASHER, SPRING

92907-06100-00

1
Out of stock

10

BAND, SWITCH CORD

437-83936-11-00

1

$3.20

In stock
