1971 Yamaha SL338B Intake Diagram

← All diagrams

Find the part on the Intake diagram for your 1971 Yamaha SL338B, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1971 Yamaha SL338B Intake Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GASKET, MANIFOLD

810-13556-09-00

1
Out of stock

2

BOLT, STUD

90116-08050-00

1
Out of stock

3

MANIFOLD, INTAKE

807-13555-01-00

1
Out of stock

4

GASKET

810-13563-09-00

1
Out of stock

5

JOINT, CARBURETOR

(810-13565-00-00)

1
Out of stock

5

JOINT, CARBURETOR

(824-13565-00-00)

1
Out of stock

6

YBS67-8 WASHER, SPRING

92990-08100-00

1

$4.52

In stock

7

NUT(6L2)

95333-08600-00

1

$3.20

In stock

8

O-RING (11M)

93210-07540-00

1

$5.77

In stock

9

WASHER, PLAIN

92990-08200-00

1

$2.56

In stock

9

WASHER, PLAIN

92990-08200-00

1

$2.56

In stock

10

BOLT, SOCKET

91317-08030-00

1

$6.17

In stock

11

GASKET

810-13566-09-00

1
Out of stock

11

GASKET

810-13566-09-00

1
Out of stock

12

BOLT, STUD

(90116-08045-00)

1
Out of stock

12

BOLT, STUD

90116-08150-00

1
Out of stock

13

. NUT

95380-08700-00

1

$3.07

In stock

14

SPACER

(810-14442-00-00)

1
Out of stock

15

SILENCER, INTAKE 1

(812-14431-00-00)

1
Out of stock

16

STAY 1

(810-14493-00-00)

1
Out of stock

17

FUNNEL

(810-14479-00-00)

1
Out of stock

18

YBS66-6 WASHER, PLAIN

92990-06200-00

—

$0.78

In stock

19

SCREW, PAN

98507-06014-00

—

$6.18

In stock

20

SILENCER, INTAKE 2

(812-14441-00-00)

1
Out of stock

21

COLLAR 8121444900

90387-06023-00

—

$7.66

In stock

22

GROMMET

(90480-13015-00)

1
Out of stock

23

WASHER, PLATE

90201-06061-00

1
Out of stock

24

SCREW, BIND (705)

98980-06016-00

—
Out of stock

25

JOINT, CARBURETOR

824-13585-00-00

1
Out of stock

26

GROMMET

(810-14435-00-00)

1
Out of stock

27

INDICATOR, CHOKE

(810-77455-00-00)

1
Out of stock

28

EMBLEM 1

(810-77451-00-00)

1
Out of stock

29

SPACER

(810-13576-00-00)

1
Out of stock

30

NOZZLE

824-13552-00-00

1
Out of stock

31

CLAMP, THROTTLE

(833-41222-00-00)

1
Out of stock
