2012 Yamaha Super Jet (SJ700BL) Hull & Deck Diagram

← All diagrams

Find the part on the Hull & Deck diagram for your 2012 Yamaha Super Jet (SJ700BL), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2012 Yamaha Super Jet (SJ700BL) Hull & Deck Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

HOSE (L380)

90445-14M25-00

1

$19.46

In stock

2

CLAMP

90465-10098-00

1

$2.24

In stock

3

JOINT, HOSE

6K8-51162-00-00

1

$11.49

In stock

4

CLAMP (6E5)

90465-13M11-00

1

$5.72

In stock

5

HOSE (L450)

90445-14M04-00

1

$18.99

In stock

6

SPOUT

FN8-6269B-00-00

1

$17.81

In stock

7

NUT

EU0-61652-00-00

1

$12.27

In stock

8

CLIP

90600-91755-00

1

$6.00

In stock

9

STRAINER, BILGE

F4R-6761D-00-00

1

$31.99

In stock

10

BASE, STRAINER BLIGE

EW2-67618-00-00

1

$37.39

In stock

11

1

$4.15

In stock

12

CLAMP (6E5)

90465-13M11-00

1

$5.72

In stock
