1990 Yamaha Super JET (SJ650D) AIR Filter Diagram

← All diagrams

Find the part on the AIR Filter diagram for your 1990 Yamaha Super JET (SJ650D), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1990 Yamaha Super JET (SJ650D) AIR Filter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

MANIFOLD 1

6M6-13641-00-94

1
Out of stock

2

GASKET

6M6-13566-A2-00

1
Out of stock

3

MANIFOLD,INTAKE

6M6-13555-01-94

1
Out of stock

4

. PIPE, JOINT 4

652-24461-00-00

1

$4.74

In stock

5

BOLT, STUD

90116-08M14-00

1

$5.53

In stock

6

NUT (661)

95380-08600-00

1

$6.23

In stock

7

.. WASHER, PLATE

92990-08600-00

1

$2.36

In stock

8

GASKET

6M6-13563-A1-00

1
Out of stock

9

PLATE

6M6-14527-02-94

1
Out of stock

10

GASKET, MANIFOLD

6M6-13556-A1-00

1

$6.00

In stock

11

HOSE (L400)

90445-10M43-00

1

$5.88

In stock

12

CLAMP

90465-10098-00

1

$2.24

In stock

13

BOLT(3RV)

97014-06035-00

1

$1.54

In stock

14

WASHER, PLAIN (646)

92990-06600-00

1

$2.48

In stock

15

REED VALVE ASSEMBLY

6R7-13610-01-00

1
Out of stock

16

. REED SET

6R7-W0004-00-00

1
Out of stock

17

BOLT(7U8)

97080-06020-00

1
Out of stock

18

WASHER, PLAIN (646)

92990-06600-00

1

$2.48

In stock

19

GASKET, VALVE SEAT

6M6-13621-A1-00

1
Out of stock

20

BOLT, WITH WASHER

90119-05M02-00

1

$3.16

In stock

21

COVER, CARB.

99999-02651-00

1
Out of stock

22

COVER, CARBURETOR 2

6M6-14284-00-8P

1
Out of stock

23

ELEMENT, AIR CLEANER

6M6-14451-00-00

1
Out of stock

24

SCREW, PAN HEAD(6B0)

97885-05016-00

1

$3.96

In stock

25

WASHER, PLAIN (646)

92990-05600-00

—
Out of stock

26

GASKET, AIR COOLER COVER 1

6M6-13674-A1-00

1

$5.08

In stock

27

PLATE

6R7-14255-00-00

1
Out of stock

28

EMBLEM

6R7-1441K-00-00

1
Out of stock
