Can-Am Sarasota 1000, 2005 Carburetor Diagram
#
Description
Price
1
Stud
DM79452
Unavailable
2
CARBURATOR GASKET - Call your local BRP dealership
DUP04960
Unavailable
3
Insulator
DUP04760
Unavailable
4
CARBURATOR GASKET - Call your local BRP dealership
DM150021
Unavailable
5
Carburator | Includes Items 5 to 17
DAM133557
Unavailable
6
Throttle Shaft
DAM133558
Unavailable
7
Choke Shaft
DAM119029
Unavailable
8
Pilot Jet 40
DM119186
Unavailable
9
Idle Screw
DAM119031
Unavailable
10
Air Screw
DAM123030
Unavailable
11
Noozle
DM150023
Unavailable
12
Main Jet 90
DM150024
Unavailable
13
Float
DAM123559
Unavailable
14
Gasket
DM119180
Unavailable
15
Chamber
DAM119027
Unavailable
16
Screw Ass'y
DAM119030
Unavailable
17
Drain Bolt
DM119187
Unavailable
18
Carburator Gasket Kit | Not Shown
DAM133543
Unavailable
