2007 Yamaha Attak (RXW10W) Intake 2 Diagram
Find the part on the Intake 2 diagram for your 2007 Yamaha Attak (RXW10W), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.
#
1
THROTTLE BODY ASSY
8FP-13750-10-00
15
SCREW, PAN
98507-06010-00
16
. PIPE 1
8FP-14348-00-00
17
PIPE 1
8FP-14348-10-00
18
SENSOR, PRESSURE
5PS-82380-00-00
22
THROTTLE SENSOR ASSY
3P6-85885-01-00
24
EXTENSION, WIRE HARNESS
8FP-82386-01-00
25
PIPE 1
5JW-14348-00-00
27
HOSE
5PS-14987-00-00
28
PIPE
8FP-14349-10-00
29
CONNECTOR
5PW-1410F-00-00
37
. PIPE
8FP-14148-00-00
41
ADJUST SCREW SET
8FP-14503-00-00
42
CLIP
8FP-13577-00-00
