2007 Yamaha Vector Mountain (RS90MW) Intake Diagram

← All diagrams

Find the part on the Intake diagram for your 2007 Yamaha Vector Mountain (RS90MW), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2007 Yamaha Vector Mountain (RS90MW) Intake Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

JOINT, CARBURETOR 1

8ES-13586-10-00

1

$74.34

In stock

2

BOLT,SOCKET

91317-06020-00

—

$2.11

In stock

3

HOSE CLAMP ASSY

90450-57016-00

1
Out of stock

4

HOSE

8ES-14294-00-00

—

$15.60

In stock

5

CLIP

90467-11028-00

1

$5.14

In stock

6

PIPE

8ES-14298-00-00

—

$21.48

In stock

7

CLIP

90467-11028-00

1

$5.14

In stock

8

CLIP

90467-11028-00

1

$5.14

In stock

9

CLAMP(4HM)

90464-13194-00

—

$1.46

In stock

10

HOSE, AIR

8ES-13895-00-00

1
Out of stock

11

CLIP(41W)

90467-08092-00

1

$6.86

In stock

12

HOSE, AIR 2

8ES-13892-00-00

1
Out of stock

13

CLIP(41W)

90467-08092-00

1

$6.86

In stock

14

CLIP (8A1)

90467-09026-00

1

$2.72

In stock

15

SILENCER, INTAKE 1

8ES-14431-00-00

—

$30.78

In stock

16

SILENCER, INTAKE 2

8ES-14441-00-00

—

$59.17

In stock

17

PLATE, ELEMENT

8ES-14472-00-00

—

$31.69

In stock

18

ELEMENT, AIR CLEANER

8ES-14451-00-00

—

$26.92

In stock

19

HOOK

8FA-14436-00-00

—

$5.08

In stock

20

DAMPER 1

8ES-14425-00-00

—

$7.49

In stock

21

SEAL

8ES-14452-00-00

1
Out of stock

22

COVER, CLEANER CASE 1

8ES-1441A-00-00

—

$87.85

In stock

23

PIPE

8ES-14419-00-00

—

$41.60

In stock

24

JOINT, AIR CLEANER 1

8ES-14453-00-00

—

$18.63

In stock

25

HOSE CLAMP ASSY

90450-67002-00

—

$10.43

In stock

26

COVER, CARBURETOR 1

8ES-14283-00-00

—

$44.63

In stock

27

HOSE (L198)

90445-11293-00

—

$6.97

In stock

28

CLIP

90467-100A1-00

—
Out of stock

29

PIPE

8ES-14148-00-00

—

$3.91

In stock

30

LABEL, CAUTION

8ES-14488-00-00

—
Out of stock

31

LABEL, INSTRUCTION

8ES-14427-00-00

—

$9.09

In stock

32

FUEL PUMP ASSY

8FA-13910-00-00

—

$154.43

In stock

33

BRACKET, FUEL PUMP

8FA-24491-00-00

—

$4.57

In stock

34

NUT, FLANGE(4MV)

95707-06500-00

—

$0.78

In stock

35

COLLAR (878)

90387-08262-00

—

$9.02

In stock

36

BOLT, FLANGE(4NM)

95027-06085-00

—

$6.85

In stock

37

STAY

8FW-12443-00-00

—

$16.52

In stock

38

BOLT, FLANGE

95817-06016-00

—

$1.49

In stock
