2005 Yamaha RS Vector Mountain (RS90MK) SKI Diagram
Find the part on the SKI diagram for your 2005 Yamaha RS Vector Mountain (RS90MK), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.
#
Description
Qty in Assembly
Price
Status
Order Qty
1
SKI 1
8FK-23711-00-BK
1
Out of stock
2
BLUE 8DM HANDLE PLASTIC
8DM-23712-00-BU
1
Out of stock
2
RED 8DM HANDLE PLASTIC
8DM-23712-00-RD
1
Out of stock
3
. COLLAR 1
8EX-F3754-00-00
1
Out of stock
4
RUNNER
8EN-23731-00-XX
1
Out of stock
38
FRONT LOWER ARM COMP. (LEFT)
8GY-23570-00-00
1
Out of stock
62
BAR, STABILIZER FRONT
8FA-2386E-00-00
1
Out of stock
64
ARM, STABILIZER
8FA-2386L-10-00
—
Out of stock
68
BOLT, FLANGE(4FM)
95814-08030-00
—
Out of stock
