2017 Yamaha RS Vector (RS90HL) Intake 2 Diagram

← All diagrams

Find the part on the Intake 2 diagram for your 2017 Yamaha RS Vector (RS90HL), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2017 Yamaha RS Vector (RS90HL) Intake 2 Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

THROTTLE BODY ASSY

8JU-13750-01-00

1
Out of stock

2

INJECTOR ASSY

8GC-13761-00-00

1

$254.51

In stock

3

O-RING

8GC-13769-00-00

1

$13.52

In stock

4

GASKET, MANIFOLD

8FP-13556-00-00

1

$12.27

In stock

5

PIPE INLET ASSEMBLY

8HF-13930-00-00

—

$286.02

In stock

6

ADJUST SCREW SET

8GL-14503-00-00

—

$13.66

In stock

7

SCREW

2C0-14216-00-00

1

$3.03

In stock

8

SENSOR, PRESSURE

1WS-82380-00-00

1
Out of stock

9

ACCELERATOR SENSOR ASSY.

8JU-85884-00-00

—

$122.88

In stock

10

SCREW

8CC-14216-10-00

1

$7.12

In stock

11

CAP

895-14169-00-00

1

$4.02

In stock

12

CLIP, PIPE

8A7-14139-00-00

1

$6.80

In stock

13

BOLT 1

8GL-13573-00-00

1

$11.66

In stock

14

WASHER

8GL-13571-00-00

1

$3.37

In stock

15

COLLAR

8GL-14534-00-00

1

$8.31

In stock

16

PIPE

5JW-14349-10-00

—
Out of stock

17

THROTTLE SENSOR ASSY

8JU-85885-00-00

—

$141.97

In stock

18

HOSE, VACUUM SENSING 3

2C0-13532-00-00

—

$12.82

In stock

19

CONNECTOR

5PW-1410F-00-00

—
Out of stock

20

PIPE

8FP-14349-00-00

—

$9.80

In stock

21

PIPE

8FP-14349-30-00

—

$4.15

In stock

22

HOSE

8JU-1410E-00-00

—

$17.71

In stock

23

HOLDER

8JU-14261-00-00

—

$7.37

In stock
