Suzuki RM250 (2006) STEERING STEM (MODEL K6) Diagram

#

Description
Price

1

STEM, STEERING | Includes Item(s) 2

51410-37F80

Unavailable

2

.BEARING (30X52X16) This part replaces 09265-30014.

09265-30035

$42.15

3

GUIDE, BRAKE HOSE

58621-37F80

$11.13

4

BOLT, GUIDE

09111-06087

$3.30

5

BOLT

51328-37F80

$6.64

6

BEARING

09265-30022

$84.82

7

NUT, STEERING

51631-37F00

$38.53

8

SEAL, STEERING UPPER DUST

51643-37F00

$31.90

9

HEAD, STEERING STEM

51310-37F70

Unavailable

10

BOLT

51328-37F80

$6.64

11

WASHER,STEM HEAD

51356-29E00

$20.30

12

NUT,STEM HEAD

51353-37F70

$45.53

13

HOLDER, HANDLE

56211-35G00

$38.53

14

BOLT, HANDLE HOLDER

51321-37F90

$8.21

15

HOLDER, HANDLE LOWER

56221-35G00

$65.62

16

CUSHION RUBBER UPPER This part replaces 56241-42AE0.

56241-42AE1

$26.03

17

CUSHION RUBBER UNDER This part replaces 56242-28C60.

56242-28C61

$26.90

18

BOLT

56321-35G00

$5.26

19

SPACER

56243-42A00

$9.07

20

NUT

08319-31107

$2.73
