Description

Price

1

GEAR ASSY, PRIMARY DRIVEN | NT:63/21

21200-37F10

$428.25

2

SPACER, PRIMARY DRIVEN GEAR

21251-37E01

$57.22

3

BEARING, PRIMARY DRIVEN | 29X34X27

09263-29009

$19.04

4

HUB, CLUTCH SLEEVE

21410-37F50

$127.37

5

PLATE, CLUTCH DRIVE

21441-37F50

$34.93

6

PLATE, CLUTCH DRIVEN

21451-37F00

$8.70

7

DISK, CLUTCH PRESSURE

21462-37F20

$77.40

8

BOLT, CLUTCH (5X25)

09116-05019

$2.31

9

NUT, CLUTCH SLEEVE HUB

09140-18013

$15.33

10

WASHER, CLUTCH HUB THR | 22.5X39

09160-22082

$15.50

11

WASHER, CLUTCH HUB

09167-22027

$4.03

12

SPRING, CLUTCH

09440-18038

$6.19

13

ROD, CLUTCH PUSH

23110-37F00

$20.48

14

PIECE,CLUTCH PUSH

23121-37F00

$19.03

15

CAMSHAFT, CLUTCH RELEASE

23200-37E02

$76.43

16

BEARING, CLUTCH RELEASE | 10.1X22X2.8

09263-10002

$9.20

17

BEARING, NO.2 | 12X16X10

09263-12024

$11.44

18

SEAL, CL RELEASE CAMSHAFT | 12X19X5

09285-12004

$5.71

Suzuki RM250 (2006) CLUTCH (MODEL K6) Diagram
