1985 Suzuki RM250 Front Caliper Diagram

← All diagrams

Find the part on the Front Caliper diagram for your 1985 Suzuki RM250, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1985 Suzuki RM250 Front Caliper Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

NO DESCRIPTION AVAILABLE | Includes Item(s) 1 - 16 This part replaces 59300-14600.

59300-14510

1
Out of stock

1

PISTON SET

59300-14820

1
Out of stock

2

..SEAL SET,PISTON This part replaces 59107-14500.

69100-04820

1
Out of stock

3

DUST SEAL

59108-14500

1
Out of stock

4

PAD SET This part replaces 59340-14600.

59300-14840

2
Out of stock

5

SPRING

59315-14600

1
Out of stock

6

SHIM

59371-14500

1
Out of stock

7

BOOT

59386-13A00

1
Out of stock

8

BOLT

59382-14500

1

$9.18

In stock

9

BOOT

59303-14500

1
Out of stock

10

BOLT

59305-14500

1
Out of stock

11

NUT

59306-14500

1
Out of stock

12

PIN

59345-14600

1
Out of stock

13

BRACKET

59351-14600

1
Out of stock

14

RETAINER

59316-14600

1
Out of stock

15

BLEEDER

59121-01A00

1
Out of stock

16

CAP

59122-01A00

1
Out of stock

17

BOLT (8X29) This part replaces 09103-08156.

09103-08409

2
Out of stock
