1995 Suzuki RM125 Handle Switch Diagram

← All diagrams

Find the part on the Handle Switch diagram for your 1995 Suzuki RM125, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1995 Suzuki RM125 Handle Switch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GRIP, THROTTLE

57110-27C00

1
Out of stock

2

ROTOR, THROTTLE

57114-14301

1
Out of stock

3

CASE ASSY, THROTTLE

57100-14302

1
Out of stock

4

COVER

57129-14302

1
Out of stock

5

SCREW This part replaces 02132-04105.

02122-0410A

1
Out of stock

6

SCREW

02112-05167

2
Out of stock

7

LEVER, BRAKE

57421-27C00

1
Out of stock

8

BOLT, BRAKE LEVER

57431-14500

1
Out of stock

9

NUT This part replaces 57442-14500.

08316-1006B

1
Out of stock

10

BOLT, ADJUST

57431-14511

1
Out of stock

11

NUT This part replaces 08310-12055.

08310-0005A

1
Out of stock

12

SPRING, RETURN

57318-14502

1
Out of stock

13

COVER, BRAKE LEVER

57341-14501

1
Out of stock

14

GRIP LH

57211-27C00

1
Out of stock

15

LEVER ASSY,CLUTCH | MODEL N/P This part replaces 57500-28C00.

57500-28C13

1
Out of stock

15

LEVER ASSY,CLUTCH | MODEL R This part replaces 57500-28C10.

57500-28C13

1
Out of stock

16

LEVER, CLUTCH

57621-28C00

1
Out of stock

17

BOLT This part replaces 57431-28C00.

57431-28C01

1
Out of stock

18

.NUT This part replaces 08319-21068.

08319-2106A

1
Out of stock

19

ADJUSTER, CABLE | MODEL N/P

57441-28C00

1
Out of stock

19

ADJUSTER, CABLE | MODEL R

57441-28C10

1
Out of stock

20

NUT

57442-28C00

1
Out of stock

21

BOLT This part replaces 01107-05167.

01500-0516B

1
Out of stock

22

HOLDER

57511-28C00

1
Out of stock

23

.BRACKET, CLUTCH LEVER HOLDER

57512-28C00

1
Out of stock

24

COVER, CLUTCH LEVER This part replaces 57341-40001.

57341-40003

1
Out of stock
