Kawasaki RIDGE® XR CREW LIMITED HVAC Control Diagram

Description

Price

11058

BRACKET,LEVER

11058-0655

$22.14

13070

GUIDE

13070-1539

$53.39

13236

LEVER-COMP,CHANGE LEVER

13236-0708

$46.03

13236A

LEVER-COMP,SHIFT

13236-0862

$76.81

13272

PLATE,SHIFT GRIP,S.BLACK

13272-7086-839

$2.29

39112

RODEND-TIE

39112-0036

$21.80

46075

GRIP

46075-0669

$13.86

54010

CABLE,SHIFT

54010-0669

$54.43

56030

LABEL,POSITION

56030-1421

$1.54

92015

NUT,LOCK,FLANGED,6MM

92015-1675

$3.29

92028

BUSHING

92028-1507

$3.99

92145

SPRING

92145-2278

$7.51

92152

COLLAR

92152-1332

$3.19

92152A

COLLAR,6.0X10X47

92152-1517

$7.32

92152B

COLLAR,6.0X10X30

92152-1518

$4.97

92152C

COLLAR

92152-2939

$15.86

92154

BOLT,FLANGED,6X16

92154-0887

$1.24

92171

CLAMP

92171-1615

$11.42

92172

SCREW,5X16

92172-0479

$1.96

130

BOLT-FLANGED,6X12

130BA0612

$1.25

130A

BOLT-FLANGED,6X20

130CA0620

$1.22

130B

BOLT-FLANGED,6X45

130CA0645

$1.11

130C

BOLT-FLANGED,6X65

130CA0665

$1.28
