Description

Price

1

Hex. Flange Screw M10 X 55

207605546

$1.74

2

Hex. Flange Screw M10 X 6

207606046

$3.38

3

Hex. Flange Screw M10 X 65

207606536

$3.61

4

Hex. Flange Elastic Nut M10

233201414

$1.26

5

Hex. Flange Elastic Nut M10

233201436

$1.74

6

Hex. Flange Elastic Nut M16

233211466

$1.53

7

Hex. Flange Elastic Nut M6

233261494

$1.26

8

Hex. Flange Elastic Nut M8

233281434

$1.74

9

Flat Washer M8

234081430

$1.74

10

Torx Screw M6 X 20

250000722

$1.34

11

Grease Fitting

250000315

$4.82

12

Flat Washer M17

250200112

$6.34

13

Seal

293200144

$4.60

15

Grease Fitting 90°

293550056

$1.37

16

Ball Bearing

293350145

$12.91

17

Spacer

706002259

$27.66

18

Rear Shock | Includes 40 to 42

706001904

$316.12

19

SPRING_COMPRESSION B-190 PAINTED - Call your local BRP dealership | Package XXC Black

706002035

$83.82

20

SPRING_COMPRESSION B-190 PAINTED - Call your local BRP dealership | STD

706000955

$78.43

21

Swaybar

706000988

$124.58

22

LH PROTECTOR - Call your local BRP dealership

706001009

Unavailable

23

RH PROTECTOR - Call your local BRP dealership

706001010

$12.66

24

Sway Bar Linkage

706001020

$12.68

25

Stabilizer Bar Bushing

706004640

$9.22

26

Bushing Holder

706001099

$31.51

27

Axial Pivot M16

706001664

$69.20

28

Black LH Swing Arm

706001860

$290.74

28

YELLOW LH SWING ARM - Call your local BRP dealership | XXC

706001868

$290.74

29

Black RH Swing Arm

706001861

$290.74

29

Yellow RH Swing Arm | XXC

706001869

$290.74

30

Suspension Arm Bushing Kit | Includes 4

703500875

$15.35

31

Suspension Arm Bushing Kit | Includes 4

703500875

$15.35

32

Spacer

706001282

$10.98

33

Rear Shock | Package-XXC, Includes 33a to 33d, 41, 42, 44

706001908

$719.99

33a

O-Ring Bushing

715900209

$13.52

33b

Bushing | XTP

706201648

$13.83

33c

Spherical Bearing

715900251

$76.12

33d

Retaining Ring

715900252

$10.98

34

Hex. Screw M8 X 85

250001035

$1.46

40

Bushing | Renegade STD

706201584

$13.83

41

Bushing Sleeve | XTP

706201586

$27.66

42

Bushing Sleeve | XTP

706201585

$27.66

44

Interior Bushing | XTP

715900210

$14.75

100

Not Available As Spare Parts

XXX

Unavailable

101

Not Available As Spare Parts

XXX

Unavailable

103

Not Available As Spare Parts

XXX

Unavailable

104

Not Available As Spare Parts

XXX

Unavailable

Can-Am Renegade 800R EFI, 2015 Rear Suspension _26T1512 Diagram
