Can-Am Renegade 500 EFI, 2011 Engine 2 Diagram

#

Description
Price

1

Pop Rivet 3/16"

390402200

$0.26

2

Socket Head Screw M5 X 10

205951046

Unavailable

3

ANTITHEFT PLATE - Call your local BRP dealership | Europe

707000692

$5.35

4

Lever

707000691

$23.05

5

Hex. Flange Screw M6 X 30, Scotch Grip | DS 650 X

207563034

$1.74

6

Hex. Flange Elastic Nut M6 x 1.0

233261414

Unavailable

7

Hex. Flange Elastic Nut M6 x 1.0

233261414

Unavailable

8

LH BALL JOINT - Call your local BRP dealership

707000545

Unavailable

9

LH HEX. NUT M6 - Call your local BRP dealership

232066414

Unavailable

10a

THREADED ROD - Call your local BRP dealership

707000579

Unavailable

10b

THREADED ROD - Call your local BRP dealership | Europe

707000661

$24.58

11

FIXING PLATE - Call your local BRP dealership | Europe

707000664

Unavailable

12

Extruded Panel Nut M4 X 0.7

250100143

Unavailable

13

Screw Socket M10 X 25 | Europe

205402556

Unavailable

14

Padlock with Key

707000666

$27.66

15

Cover Lock | Europe

707000667

$12.91

16

Torx Screw M4 X 16

250000750

$1.37

17

Was 409901800 Tubing (13 mm)

219704400

Unavailable

18

Hex. Nut M8

232081414

Unavailable

19

ADJUSTMENT BLOCK - Call your local BRP dealership | Europe

707000668

$22.28

20

Hex. Nut M6

232061600

Unavailable

21

PIVOT - Call your local BRP dealership

707000575

Unavailable

22

BUSHING - Call your local BRP dealership

707000576

Unavailable

23

BALL BEARING - Call your local BRP dealership

293350039

$12.28

24

Hex. Flange Screw M6 X 25

207662544

Unavailable

25

Spring

707000577

Unavailable

26

Lever Arm

707000783

$16.89

27

Loctite 243, 10 ml

293800060

$20.77

28

LEVER BUTTON - Call your local BRP dealership

705500022

Unavailable

29

RH Ball Joint

707001959

Unavailable

30

Washer

506151252

Unavailable

31

Hex. Elastic Stop Nut M8

232581414

Unavailable

32

Cover OPS

707000410

Unavailable

33

Hex. Flange Screw M6 X 12

210261250

$1.56
