Description

Price

1

Outlet Power Kit, 12 Volts

861507200

$30.52

2

Clip

270000141

$8.33

3

Pop Rivet 3/16"

390402400

$0.25

4

Clip

414227300

$1.45

5

Mount Dart

293730040

$0.86

6

Was 293550004 Dielectric Grease, 150 g

219704453

$37.66

7

Housing Support, Black

710000159

Unavailable

8

Elastic Stop Nut M5

232551414

$0.72

9

PHILLIPS SCREW M5 X 12 - Call your local BRP dealership

208651241

$0.98

10

Ignition Switch Ass'y | Includes 17 to 21

710000192

Unavailable

10

BLANK KEY (A TYPE) - Call your local BRP dealership

710000137

Unavailable

10

BLANK KEY (B TYPE) - Call your local BRP dealership

710000101

$15.35

11

Tie Wrap 368 mm

293750008

$0.85

12

Tie Wrap 142 mm

293750002

$0.88

13

Tie-Rap 180 mm

414115200

$0.09

14

Tie Wrap 94 mm | 4X4

293750001

$0.83

15

Speedometer (MPH/US)

710000296

Unavailable

16

RH Warning Lamp

710000310

Unavailable

17

Multi-function Switch | Includes 32 - 37. 7439/7440/7473 (Red/Rouge). .

710000196

Unavailable

18

Nut

414303600

Unavailable

19

Lock Washer 4 mm

234141601

$1.09

20

HEADLAMP ASS'Y - Call your local BRP dealership | Includes 31 to 34

710000174

Unavailable

21

LAMP SUPPORT - Call your local BRP dealership

705000283

$20.74

22

LAMP HOUSING - Call your local BRP dealership

705000284

Unavailable

23

BULB - Call your local BRP dealership

710000176

Unavailable

24

Tail Light Housing

710000102

Unavailable

25

TAIL LIGHT LENS, RED - Call your local BRP dealership

710000055

Unavailable

26

Bulb

520000758

$7.49

27

GASKET - Call your local BRP dealership

710000129

$8.43

28

PAN HEAD PHILLIPS SCREW M5 X 60 - Call your local BRP dealership

208656091

$0.91

29

Hex. Flange Elastic Nut M5

233251414

$1.66

30

SCREW M5 X 30 - Call your local BRP dealership

205453046

Unavailable

31

Handle

572106600

$9.31

32

HEX. SCREW K40 X 40 - Call your local BRP dealership

250000008

$1.09

33

SPRING - Call your local BRP dealership

710000285

$5.35

34

Spring

517168600

$6.91

35

LIGHT COVER - Call your local BRP dealership

709400102

$8.43

36

Flat Washer 4 mm, Stainless

234042600

$0.92

37

Flat Washer 4 mm

234040600

$0.46

Can-Am Quest, Green/vert, 2002 Electrical Accessories Diagram
