1986 Yamaha Phazer (PZ480EK) Carburetor Diagram

← All diagrams

Find the part on the Carburetor diagram for your 1986 Yamaha Phazer (PZ480EK), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1986 Yamaha Phazer (PZ480EK) Carburetor Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

CARBURETOR

80L-14100-04-00

1
Out of stock

2

SCREW, PILOT ADJUSTING

620-14211-00-00

1
Out of stock

3

SPRING, AIR ADJUSTING

82A-14134-00-00

1
Out of stock

4

WASHER, VALVE SEAT

214-14195-00-00

1
Out of stock

5

VALVE SEAT ASSY

168-14190-15-00

1
Out of stock

6

PIN,FLOAT

8M6-14186-00-00

1
Out of stock

7

FLOAT ASSY

8M6-14185-00-00

1
Out of stock

8

GASKET

286-14198-00-00

1
Out of stock

9

HOLDER

8M6-14261-00-00

1
Out of stock

10

CAP, PLUNGER

8G8-14174-00-00

1
Out of stock

11

SPRING, PLUNGER

127-14135-00-00

1
Out of stock

12

PLUNGER, STARTER

8G8-14171-00-00

1
Out of stock

13

GASKET, FLOAT CHAMBER

8M6-14126-00-00

1
Out of stock

14

BODY, FLOAT CHAMBER

8M6-14181-00-00

—
Out of stock

15

JET, PILOT (# 95)

193-14142-95-00

1
Out of stock

16

. SPRING, THROTTLE STOP

3F7-14133-00-00

1
Out of stock

17

. STOP SCREW SET

12R-1490K-00-00

1
Out of stock

18

. ROD, PUSH

584-14992-00-00

1
Out of stock

19

. CLIP

256-14937-00-00

1
Out of stock

20

NUT, WIRE ADJUSTING

802-14161-00-00

—
Out of stock

21

CABLE ADJUST SCREW SET

12G-14106-00-00

—
Out of stock

22

SCREW,THROTTLE

80L-14122-00-00

—
Out of stock

23

SPRING

8X0-14500-00-00

—
Out of stock

24

CAP

8A7-14169-00-00

—
Out of stock

25

. NUT

8V0-14358-00-00

1
Out of stock

26

JET, MAIN (#135)

3G2-14231-27-00

—
Out of stock

26

JET, MAIN (#140)

3G2-14231-28-00

—
Out of stock

26

JET, MAIN (#145)

3G2-14231-29-00

—
Out of stock

26

JET, MAIN (#150)

3G2-14231-30-A0

—
Out of stock

26

. UNAVAILABLE IN PRICE BOOK (3G2-14231-77-A0)

3G2-14231-77-A1

1
Out of stock

26

. JET, MAIN (1525) (3G2-14231-81)

3G2-14231-81-A0

1
Out of stock

26

JET,MAIN #122.5

3G2-1423A-75-A1

—
Out of stock

26

JET,MAIN #127.5

3G2-1423A-76-00

—
Out of stock

26

JET,MAIN #137.5

3G2-1423A-78-00

—
Out of stock

26

JET,MAIN #147.5

3G2-1423A-80-A0

—
Out of stock

26

JET MAIN (#143.8)

3G2-1423E-57-00

—
Out of stock

27

CAP

8V0-14118-00-00

—
Out of stock

28

. SPRING, THROTTLE 2

80L-14932-00-00

1
Out of stock

29

COLLAR

80L-14534-00-00

—
Out of stock

30

COLLAR

80L-14535-00-00

—
Out of stock

31

SPRING, THROTTLE STOP

8X0-14133-00-00

—
Out of stock

32

SWITCH, CARBURETOR

87S-8259A-01-00

—
Out of stock

33

WASHER, PLUG SCREW

22F-14117-00-00

—
Out of stock

34

COLLAR

80L-14264-00-00

—
Out of stock

35

CAP

895-14169-00-00

—
Out of stock

36

NOZZLE, MAIN

8Y2-14941-3A-00

—
Out of stock
