1976 Yamaha PR440 Brake Diagram

← All diagrams

Find the part on the Brake diagram for your 1976 Yamaha PR440, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1976 Yamaha PR440 Brake Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

DISC, BRAKE

(8A2-25711-00-00)

1
Out of stock

2

BODY, CALIPER 2

(874-25741-01-00)

1
Out of stock

3

CALIPER BODY 1

(874-25730-00-00)

1
Out of stock

4

PAD, CALIPER

(826-25732-09-00)

1
Out of stock

5

PIN (810)

90249-06012-00

—

$9.91

In stock

6

PIN

90249-06009-00

1
Out of stock

7

PIN, COTTER

91490-20025-00

1

$1.31

In stock

8

PIN, W/ HOLE (8J2)

90240-08068-00

—

$5.29

In stock

9

.. WASHER, PLATE

92990-08600-00

1

$2.36

In stock

10

SPRING, TORSION

90508-29148-00

1
Out of stock

11

SPRING, TORSION

(90508-26147-00)

1
Out of stock

12

BOLT(4MX)

97017-05030-00

1

$6.68

In stock

13

NUT, HEXAGON SMALL

95317-05700-00

1

$6.18

In stock

14

WASHER, LOCK

90215-17045-00

1
Out of stock

15

NUT, SPEC''L SHAPE

(90179-14059-00)

1
Out of stock

16

SHIM 1

137-17427-00-06

1
Out of stock

16

SHIM 1

(137-17427-00-09)

1
Out of stock

16

SHIM 1

328-17427-00-02

1
Out of stock

16

SHIM 1

328-17427-00-03

1
Out of stock
