Description

Price

1

Front Drive Axle Ass'y | 4X4 / Includes 1 to 5

705400912

$175.35

2a

Rubber Boot Kit | 4X4 / Includes 3 to 5

703500255

Unavailable

2b

Oetiker Gear Clamp 44.0MM | 4X4

293650138

$8.57

6

Front Bushing Shaft Kit | 4X4

703500678

$104.58

7

Wear Ring | 4X4

705400036

$25.35

8

Front Differential | Includes 8 to 31

703500907

$1,476.89

9

Oil Seal | 4X4

705401481

$18.43

10

Nut | 4X4

705401603

$36.89

11

Ball Bearing | 4X4

705500260

$30.74

12

10 TEETH PINION - Call your local BRP dealership

705501588

Unavailable

13

Needle Bearing | 4X4

705500261

Unavailable

14

Ball Bearing | 4X4

705401606

$49.20

15

Ball Bearing | 4X4

293350044

$30.74

16

Ens Differentiel*Differential Kit | 4X4

703500871

$710.74

19

Screw | 4X4

705401601

$9.29

20

FRONT COVER - Call your local BRP dealership

705400762

Unavailable

21

Seal | 4X4

705500265

$16.12

22

Front Cover

705400646

Unavailable

23

VENT VALVE - Call your local BRP dealership | 4X4

705500893

$14.37

24

Drain Plug | 4X4

705500894

$11.06

27

O-Ring | 4X4

705500267

$6.25

28

Gasket | 4X4

705401618

$17.66

29

Pinion Gear Shim 1.67 mm

705502061

$16.12

29

Pinion Gear Shim .022"

705500075

Unavailable

30

Shim | 4X4

705401604

$55.35

31

Shim | 4X4

705401604

$55.35

32

Fill Level Plug | 4X4

705500504

$7.61

33

Copper Washer | 4X4

705500506

$0.36

34

RH Half Shaft | Includes 34 to 39

705401579

$233.82

35

CV Joint

705500560

Unavailable

36

Wheel Boot Kit

705400511

$41.51

36a

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

$9.71

36b

OETIKER CLAMP 70MM - Call your local BRP dealership

293650194

$14.06

37

Differential Boot Kit

705400512

$41.51

37a

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

$9.71

37b

OETIKER CLAMP 67MM - Call your local BRP dealership

293650193

$16.12

39

CIRCLIP - Call your local BRP dealership | 4X4

705400042

Unavailable

40

LH Knuckle

705400816

$203.05

41

RH Knuckle

705400818

$203.05

42

LH Half Shaft | Includes 42 to 47

705401578

$233.82

43

CV Joint

705500560

Unavailable

44

Wheel Boot Kit

705400511

$41.51

44a

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

$9.71

44b

OETIKER CLAMP 70MM - Call your local BRP dealership

293650194

$14.06

45

Differential Boot Kit

705400512

$41.51

45a

OETIKER CLAMP 23MM - Call your local BRP dealership

293650192

$9.71

45b

OETIKER CLAMP 67MM - Call your local BRP dealership

293650193

$16.12

47

CIRCLIP - Call your local BRP dealership | 4X4

705400042

Unavailable

48

Ball Bearing

293350150

$52.99

49

Oetiker Gear Clamp 44.0MM | 4X4

293650138

$8.57

50

Circlip

293370019

$4.98

51

Hex. Flange Screw M10 X 125

230602546

$6.08

52

Hex. Flange Elastic Nut M10

233201436

$1.74

53

Wear Sleeve | 4X4

705501121

$7.28

54

LH WHEEL HUB ASSEMBLY - Call your local BRP dealership | 4X4 / Includes 65 to 66

705501713

Unavailable

55

Wheel Stud M10 X 1.25 | 2X4

250300055

$3.28

56

Conical Spring Washer M18

250200171

$5.28

57

Hex. Flange Castellated Nut M18

232291413

$2.82

58

Cotter Pin

250400036

$1.74

59

Rubber Bellow | 4X4

705400552

$6.02

60

Oetiker Clamp

293650042

$1.40

61a

WHEEL CAP - Call your local BRP dealership

705400680

$11.92

61b

Wheel Cap | STD

705400563

$16.12

62

Front Tire | XT

705400606

$123.82

62

Front Tire | XT

705400326

$123.82

62

Front Tire | STD Europe

705401626

$204.58

62

Tire 205 X 80 R12

705402890

$133.82

63a

RIM_12 INCH X 6 - Call your local BRP dealership | XT (Except Camo)

705400648

$141.51

63b

RIM_12 INCH X 6 - Call your local BRP dealership | STD

705400689

$103.82

64a

Rim Valve With Cap

705400193

$6.69

64b

1/2 Oz Weight

219704465

$4.35

64c

Valve Cap

293000110

$1.18

65

Steel Wheel Nut

250100042

$2.48

65

Chrome Wheel Nut M10 X 1.25 | XT

250100185

$2.48

66

Wear Sleeve

705400780

$7.28

67

Flat Washer M12

250200102

$1.74

68

HEX FLANGED SCREW M12 X 16, SCOTCH GRIP - Call your local BRP dealership

250000378

Unavailable

70

Synthetic Grease, 400 G

293550010

Unavailable

71

HOUSING - Call your local BRP dealership | 4X4

705400169

Unavailable

72

Actuator Ass'Y | Includes 72 to 74

715900502

$457.66

72a

Circlip | 4X4

293370042

$3.11

73

Fork | 4X4

705400274

$16.12

74

O-Ring

293300117

$4.28

75

Hex. Flange Screw M8 X 20, Scotch Grip | 4X4

250000137

$3.23

76

UNION SHAFT - Call your local BRP dealership | 4X4

705400917

$97.99

77

Pressure Screw M8 X 8 | 4X4

206580890

$1.65

78

Dowell Pin | 4X4

250400025

$7.37

79

Ball Bearing | 4X4

705400249

$24.58

80

Slider | 4X4

705402139

$46.12

81

Circlip | 4X4

293370029

$5.52

82

Circlip | 4X4

293370030

$2.75

83

SWITCH - Call your local BRP dealership | 4X4

710000324

Unavailable

84

Coupling Sleeve | 4X4

705400389

$32.28

85

Oil Seal | 4X4

293250138

$23.05

86

Shifter Lever Plate | 4X4

705401553

$16.89

87

Copper Washer

705601628

$4.34

88

Loctite 243, 10 ml

293800060

$20.77

89

Socket Head Screw M8 X 20, Scotch Grip

250000136

$3.06

90

O-Ring

293300091

$7.37

Can-Am Outlander Max 400 EFI, 2011 Drive System, Front Diagram
