Kawasaki Ninja® ZX™-9R Battery Case Diagram

#

Description
Price

130

BOLT-FLANGED

130J0610

Unavailable

130A

BOLT-FLANGED,6X16,BLACK

130J0616

Unavailable

130B

BOLT-FLANGED,6X25

130J0625

Unavailable

550

PIN-COTTER,4.0X25

550D4025

Unavailable

11012

CAP,BUNGEE CORD HOOK

11012-1589

$7.63

11047

BRACKET,IGNITION COIL

11047-1345

Unavailable

11047A

BRACKET,RADIATOR,LH

11047-1853

Unavailable

11048

BRACKET,RADIATOR,RH

11048-1357

Unavailable

11048A

BRACKET,IGNITER

11048-1683

Unavailable

11048B

BRACKET,LWR COWLING,LH

11048-1777

Unavailable

11048C

BRACKET,LWR COWLING,RH

11048-1780

Unavailable

11048D

BRACKET,HELMET HOOK,LH

11048-1793

Unavailable

11048E

BRACKET,HELMET HOOK,RH

11048-1795

Unavailable

11048F

BRACKET,FUEL PUMP&FILTER

11048-1796

Unavailable

13270

PLATE,FUEL TAP KNOB

13270-1171

Unavailable

14090

COVER

14090-1297

Unavailable

14090A

COVER,FUEL TAP KNOB

14090-1410

Unavailable

27012

HOOK,BUNGEE CORD,FR

27012-1474

Unavailable

27012A

HOOK,BUNGEE CORD,RR

27012-1475

$15.64

32037

BRACKET-SHOCKABSORBER

32037-1657

Unavailable

34003

HOLDER-STEP

34003-1327

$37.75

35011

STAY,RR,LH,G.GRAY

35011-1667-GD

$100.72

35011A

STAY,RR,RH,G.GRAY

35011-1668-GD

$146.97

35011B

STAY,FR,LH,G.GRAY

35011-1699-GD

$163.50

35011C

STAY,FR,RH,G.GRAY

35011-1700-GD

$156.12

55020

GUARD,RR MASTER CYLINDER

55020-1502

$35.00

92015

NUT,FLANGED,6MM

92015-1367

$2.93

92015A

NUT,FLANGED,8MM

92015-1406

$3.53

92015B

NUT,FLANGED,16MM

92015-1881

$21.63

92015C

NUT,16MM

92015-1953

$5.71

92027

COLLAR,L=14.1

92027-1920

$5.45

92072

BAND,L=168

92072-1306

$10.88

92072A

BAND,BATTERY,L=450

92072-1309

Unavailable

92150

BOLT,SOCKET,10X25

92150-1268

$4.93

92150A

BOLT,SOCKET,8X20

92150-1839

$1.81

92150B

BOLT,SOCKET,8X30

92150-1843

$3.11

92160

DAMPER

92160-1162

$3.97
