Kawasaki Ninja ZX-4R ABS Fuel Injection Diagram

Description

Price

21175

CONTROL UNIT-ELECTRONIC

21175-1855

$1,134.05

21176

SENSOR,WATER TEMP

21176-0009

$63.44

21176A

SENSOR,AIR TEMPERATURE

21176-0048

$24.07

21176B

SENSOR,VEHICLE-DOWN

21176-0704

$84.36

21176C

SENSOR,GEAR POSITION

21176-0852

$145.08

21176D

SENSOR,OXYGEN

21176-0931

$290.02

92055

RING-O,9.5X1.9

92055-0016

$7.06

92055A

RING-O

92055-0917

$3.27

92154

BOLT

92154-3764

$1.47

92161

DAMPER

92161-0951

$14.14

92161A

DAMPER,ECU

92161-2487

$22.60

92172

SCREW,TAPPING,5X16

92172-0790

$0.85

411

WASHER-PLAIN,6MM

411AA0600

$2.39
