2025 Kawasaki Ninja 1100SX Se Front Brake Diagram

← All diagrams

Find the part on the Front Brake diagram for your 2025 Kawasaki Ninja 1100SX Se, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2025 Kawasaki Ninja 1100SX Se Front Brake Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11061

GASKET,DISC PLATE

11061-0029

1
Out of stock

21007

ROTOR,FR WHEEL

21007-0701

1
Out of stock

41080

DISC,FR,BLACK+BLK

41080-0770-18U

1
Out of stock

43080

CALIPER-SUB-ASSY,FR,LH

43080-0219

1
Out of stock

43080A

CALIPER-SUB-ASSY,FR,RH

43080-0220

1
Out of stock

43082

PAD-ASSY-BRAKE

43082-0226

1
Out of stock

92154

BOLT,SOCKET,8X30

92154-1865

1
Out of stock

92154A

BOLT,FLANGED,10X60

92154-4473

1
Out of stock

99999

KIT.,DUST SEAL

99999-0738

1
Out of stock

99999A

KIT.,CALIPER PISTON

99999-0739

1
Out of stock

99999B

KIT.,BRAKE-PAD FIXING PARTS

99999-0747

1
Out of stock
