Kawasaki MULE PRO-FX™ 1000 HD EDITION Fuel Injection Diagram

Description

Price

11058

BRACKET,ECU

11058-0323

$13.64

21175

CONTROL UNIT-ELECTRONIC

21175-1879

$883.17

21175A

CONTROL UNIT-ELECTRONIC

21175-1880

$883.17

21176

SENSOR,WATER TEMP

21176-0009

$63.44

21176A

SENSOR,VEHICLE-DOWN

21176-0026

$79.06

21176B

SENSOR,AIR TEMPERATURE

21176-0048

$24.07

21176C

SENSOR,PRESSURE

21176-0906

$226.99

21176D

SENSOR,OXYGEN

21176-1192

$212.96

27010

SWITCH,OIL PRESSURE

27010-1313

$36.57

92009

SCREW,TAPPING,5X16

92009-1264

$2.51

92015

NUT,5MM

92015-1627

$4.69

92055

RING-O,9.5X1.9

92055-0016

$7.06

92066

PLUG

92066-0862

$1.10

92072

BAND,OS170-FT7(BLACK)

92072-1414

$2.97

92150

BOLT,SOCKET,5X20

92150-1019

$3.61

92161

DAMPER

92161-0673

$4.85

92161A

DAMPER,ECU

92161-2481

$5.86

92170

CLAMP

92170-2043

$1.08

92172

SCREW,TAPPING,6X16

92172-0739

$0.85

92192

TUBE

92192-2633

$5.02
