Kawasaki MULE™ 4010 TRANS4x4® DIESEL Carrier(s) Diagram

#

Description
Price

11012

CAP

11012-1784

$4.74

11065

CAP

11065-0126

$2.34

13107

SHAFT

13107-0082

$58.67

13168

LEVER

13168-0090

$9.15

13272A

PLATE,SIDE,RR,LH,W.GREEN

13272-0089-398

$167.12

13272C

PLATE,SIDE,RR,RH,W.GREEN

13272-0090-398

$167.12

13272D

PLATE,SIDE,FR,LH,D.R.RED

13272-0501-16M

$110.58

13272E

PLATE,SIDE,FR,LH,W.GREEN

13272-0501-398

$111.76

13272F

PLATE,SIDE,FR,LH,S.GREEN

13272-0501-42F

$111.76

13272G

PLATE,SIDE,FR,RH,D.R.RED

13272-0502-16M

$110.58

13272H

PLATE,SIDE,FR,RH,W.GREEN

13272-0502-398

$111.76

13272I

PLATE,SIDE,FR,RH,S.GREEN

13272-0502-42F

$111.76

13272L

PLATE,SIDE,RR,LH,D.R.RED

13272-1233-16M

$162.35

13272M

PLATE,SIDE,RR,LH,S.GREEN

13272-1233-42F

$164.10

13272N

PLATE,SIDE,RR,RH,D.R.RED

13272-1234-16M

$162.35

13272O

PLATE,SIDE,RR,RH,S.GREEN

13272-1234-42F

$164.10

14091

COVER,ENCLOSURE,LH

14091-7546

$60.76

14091A

COVER,ENCLOSURE,RH

14091-7562

$60.76

27012

HOOK,TAIL GATE

27012-0022

$4.81

32085

STOPPER

32085-7501

$6.61

35011

STAY,CARRIER STOPPER

35011-1648

$29.46

39156

PAD,ENCLOSURE COVER,LH

39156-0007

$40.64

39156A

PAD,CARRIER,MIDDLE

39156-0465

$71.76

39156B

PAD,CARRIER,FR

39156-0466

$24.44

39156C

PAD,CARRIER,RR

39156-7505

$76.47

39156D

PAD,ENCLOSURE COVER,RH

39156-7507

$20.78

39156E

PAD,ENCLOSURE COVER,RH

39156-7508

$20.78

53004

MAT,CARRIER,MIDDLE

53004-0036

$22.98

53004A

MAT,CARRIER,RR

53004-0037

$16.00

53004B

MAT,CARRIER,FR

53004-0038

$50.45

53009

HINGE,CARRIER

53009-7501

$47.50

53029A

CARRIER,BASE PLATE,W.GREEN

53029-0061-398

$960.88

53029B

CARRIER,BASE PLATE,BLACK

53029-0313-10

Unavailable

53045

HOOK-ASSY,TAIL GATE

53045-0004

$26.21

53062

GATE-TAIL,D.R.RED

53062-7503-16M

$405.17

53062A

GATE-TAIL,W.GREEN

53062-7503-398

$424.62

53062B

GATE-TAIL,S.GREEN

53062-7503-42F

$424.62

92009

SCREW,TAPPING,6X16

92009-1166

$4.18

92009A

SCREW,6X16

92009-1621

Unavailable

92015

NUT,6MM

92015-1094

$6.55

92015A

NUT,LOCK,FLANGED,6MM

92015-1675

$3.32

92022

WASHER,7X18X1.2

92022-1545

$0.84

92039

RIVET

92039-1150

$3.53

92043

PIN,12X65

92043-1428

$7.69

92075

DAMPER

92075-1817

$4.67

92139

BUSHING,REAR SCREEN

92139-7501

$4.14

92145

SPRING,TENSIONER

92145-1215

$3.55

92161

DAMPER

92161-0258

$3.22

92161A

DAMPER

92161-7510

$3.34

92172

SCREW,TAPPING,6X20

92172-0488

$2.11

92190

TUBE,13X16X200

92190-1401

$4.63

92210

NUT,FLANGED,8MM

92210-0555

$1.47

92210A

NUT,LEAF SPRING,6MM

92210-0624

$1.66

130

BOLT-FLANGED,6X30

130BA0630

$1.13

130A

BOLT-FLANGED,8X20

130BB0820

$0.71

130B

BOLT-FLANGED,8X30

130BB0830

$3.42

130C

BOLT-FLANGED,8X50

130BB0850

$3.60

220

SCREW-PAN-CROS,6X10

220AB0610

$1.33

554

PIN-SNAP,12MM

554DA1200

$3.03
