Ski-Doo Mach Z R Millennium Edition, 2000 Front Arm Diagram

#

Description
Price

1

Helicoidal Lock Washer M10 | XT Models

234101601

Unavailable

2

Hex. Elastic Stop Nut M8

232581414

Unavailable

3

Bushing

414936000

Unavailable

4

Hex. Screw M8 X 40

207084044

Unavailable

5

WASHER - Call your local BRP dealership

517078700

Unavailable

6

Welded Front Arm

503171100

Unavailable

7

Hardened Washer

503175400

Unavailable

8

SHAFT - Call your local BRP dealership

503190387

Unavailable

9

Shock

503188913

Unavailable

10

Free Piston

415097900

Unavailable

11

O-Ring

414888312

$16.12

12

AIR VALVE - Call your local BRP dealership

414888314

$29.20

13

Air Valve Cap

415127405

Unavailable

14

Axle

503151600

$15.35

15

Lock Washer 8 mm

234181401

Unavailable

16

Hex. Screw M8 X 30

207183044

Unavailable

17

STOPPER STRAP - Call your local BRP dealership

503190782

Unavailable

18

Lower Axle

503174900

Unavailable

19

Spring

415090600

Unavailable

20

Bushing

503189324

$11.17

21

HEX. SCREW M10 X 60 - Call your local BRP dealership

207006044

Unavailable

22

Grease Fitting

408200700

Unavailable

23

Welded Shock Support

503188976

Unavailable

24

Hex. Screw M12 x 40

207124044

Unavailable

25

Spring Stopper

706200881

$10.30

26

Protector

503193663

Unavailable

27

Loctite 271, 10 ml

293800005

Unavailable

28

SYNTHETIC GREASE, 400 G - Call your local BRP dealership

219700417

Unavailable

29

HEX. SCREW M8 X 75 - Call your local BRP dealership

207087544

Unavailable

30

Flat Washer 8 mm

234081410

Unavailable

31

Flat Washer 10 mm

234001410

Unavailable

32

Flat Washer 12 mm

234021410

$0.68

33

Cushion

414917900

Unavailable

34

Hex. Screw M8 X 55

207085544

$1.62

35

HEX. SCREW M12 X 60 - Call your local BRP dealership

207026044

Unavailable

36

Lock Washer 12 mm

234120602

Unavailable

37

SHAFT - Call your local BRP dealership

503189313

Unavailable

38

CUSHION - Call your local BRP dealership

503189323

Unavailable

39

Lever

503158500

Unavailable

40

Tie Rod Shaft

503158600

Unavailable

41

Tie Rod

503187100

Unavailable

42

Hex. Screw M8 X 50

207085044

Unavailable

43

Loctite 243, 10 ml

293800060

$20.77

44

Flat Washer 12 mm

234021410

$0.68

45

HPG Decal (Europe)

516000182

Unavailable

46

Hex. Screw M8 X 25

207182544

Unavailable

47

Cushion

414917900

Unavailable

48

Spring Spacer

503182200

Unavailable

49

Spring

415090500

Unavailable

50

Rear Shock

503188912

Unavailable

51

Free Piston

415097900

Unavailable

52

O-Ring

414888312

$16.12

53

AIR VALVE - Call your local BRP dealership

414888314

$29.20

54

Air Valve Cap

415127405

Unavailable

55

Adjustment Cam

505073625

Unavailable

56

Spring Guide

503191872

Unavailable
