Ski-Doo Mach Z, 2001 Cylinder, Exhaust Manifold Diagram

#

Description
Price

1

GASKET 0.6 MM - Call your local BRP dealership

420931622

Unavailable

GASKET 0.4 MM - Call your local BRP dealership

420931621

Unavailable

GASKET 0.3 MM - Call your local BRP dealership

420931620

Unavailable

2

Socket Head Screw M6 X 25

205062544

$0.88

3

Lock Washer M6, Black

234161471

$0.52

4

Cylinder (Nicasil Coated)

420923480

Unavailable

5

Exhaust Valve

420854303

Unavailable

6

Oil Seal | Included in gasket kit

420950732

Unavailable

7

Gasket

420250239

$6.62

8

Valve Housing

420854266

$93.82

9

Socket Head Screw M6 x 16

420241237

Unavailable

10

Hose Spring This part replaces 420838253.

420838255

$6.11

11

Exhaust Bellows

420260723

$35.07

12

Hose Spring This part replaces 420239048.

420939281

Unavailable

13

Exhaust Valve This part replaces 290253257.

420854449

$29.87

14

SPRING - Call your local BRP dealership

420239941

Unavailable

15

Valve Cover

420911552

$37.66

16

Adjuster Screw

420241221

Unavailable

17

Hex. Tapping Screw M5 X 20

420841555

$1.68

18

Hex. Collar Screw M8 x 45

420640432

Unavailable

19

Collar Hex. Screw M8 x 53.5

420640441

Unavailable

20

O-Ring | Grand Touring 500.

420831792

Unavailable

21

SEAL RING - Call your local BRP dealership

420931320

Unavailable

22

O-Ring

420430373

Unavailable

23

Water Tube

420922450

Unavailable

24

Cylinder Head

420913638

Unavailable

25

O-Ring

420430782

Unavailable

26

O-RING - Call your local BRP dealership

420950310

Unavailable

27

Cylinder Head Cover

420923493

Unavailable

28

Hex. Collar Screw M8 X 68.5 This part replaces 420640951.

420640952

Unavailable

29

RETAINING DISK - Call your local BRP dealership

420927745

Unavailable

30

SEALING RING - Call your local BRP dealership

420931270

Unavailable

31

Exhaust Socket

420922485

Unavailable

32

WASHER-LOCK DIN.128 - Call your local BRP dealership

420945751

Unavailable

33

Hex. Screw M6 X 40

207064044

$1.48

34

Gasket

420850338

$10.28

35

COVER - Call your local BRP dealership

420926260

$24.58

36

TAPTITE SCREW M6 X 16 - Call your local BRP dealership

420240580

Unavailable

37

PLUG SCREW - Call your local BRP dealership

420240480

Unavailable

38

Aluminum Sealing Ring

420250016

Unavailable

39

Plug screw

420841924

Unavailable

40

Gasket

420850552

$7.92

41

Exhaust Socket

420978818

Unavailable

42

GASKET SET - Call your local BRP dealership

420888790

Unavailable

43

Loctite 243, 10 ml

293800060

$20.77

44

LUBRICANT LOCTITE LB 8150 - Call your local BRP dealership

293800023

Unavailable

45

Dow Corning 111, 150 g

413707000

$57.82
