Suzuki LT80S (1995) CRANKCASE LEFT COVER Diagram

#

Description
Price

1

COVER, CLUTCH

11341-40B01

Unavailable

2

GASKET, CLUTCH COVER | MODEL H/J/K/L/M This part replaces 11482-40B01.

11482-40B10

$17.46

2

GASKET, CLUTCH COVER | MODEL N/P/R/S

11482-40B10

$17.46

3

PIN

04211-13189

$2.19

4

BOLT | MODEL H/J/K/L/M/N/P This part replaces 07120-06258.

07120-06257

$2.80

4

BOLT, CENTER | MODEL R/S This part replaces 07120-06253.

07120-0625A

$2.50

5

BOLT | MODEL H/J/K/L/M/N/P This part replaces 07120-06358.

07120-0635B

$3.10

5

BOLT | MODEL R/S This part replaces 07120-06353.

07120-0635B

$3.10

6

BOLT | MODEL H/J/K/L/M/N/P This part replaces 07120-06458.

07120-0645B

$3.08

6

BOLT | MODEL R/S This part replaces 07120-06453.

07120-0645B

$3.08

7

BOLT | MODEL H/J/K/L/M/N/P This part replaces 01547-06958.

01547-06957

$3.14

7

.BOLT | MODEL R/S This part replaces 01547-06953.

01547-0695B

$3.04

8

GASKET (7X15X0.6)

09168-07001

$2.10

9

SCREW, WATER DRAIN

09128-08004

$1.84

10

GASKET (8.2X14X1) This part replaces 09168-08008.

09168-08016

$1.64

11

CASE, RECOIL STARTER This part replaces 18110-40B00.

18110-40BK0

Unavailable

12

GASKET, RECOIL STARTER

18299-40B01

$8.10

13

BOLT | MODEL H/J/K/L/M/N/P

01547-06127

$1.67

13

BOLT | MODEL R/S This part replaces 01547-06123.

01547-0612B

$1.22

14

BOLT | MODEL H/J/K/L/M/N/P

01547-06557

$2.34

14

BOLT | MODEL R/S This part replaces 01547-06553.

01547-0655B

$2.74

15

GASKET

09168-06024

$2.19

16

DUCT, BELT COOLING, IN

17161-40B01

$13.43

17

CLIP

09401-30404

$4.38

18

CLIP This part replaces 09401-34402.

09401-33401

$6.73
